ADD-ON SENSOR HARNESSES ANALOG BLOCK WATER PRESSURE SENDER
SMARTCRAFT RIGGING
ADVANCED SOUND CONTROL KIT

8M0145165
Optional kit to add analog block water pressure feature to a digital engine
Applicable to DTS 3.4L V6 and 4.6L V8 engines (mechanical engines have this
8M0143359 sensor as standard)
Provides an interface for a dash‑mounted dedicated button or switch to manipulate
the Advanced Sound Control capability on Verdao AMS applications (4.6L V8 only) BOAT HARNESS - FUEL/PADDLE
Optional kit for Verado AMS applications (4.6L V8) that is not required when a
version 9 SmartCraft gauge or a VesselView403/502/702/903 or compatible Simrad
or Lowrance display is used (control capability is within the user interface).
OIL LEVEL STATUS KIT

84-8M0146321
6‑Pin male harness connects tanks and paddle wheel to SmartCraft system
For all Verado and 2006 and newer SmartCraft compatible outboard engines 75
HP and above. Also fits MCM/MIE engines (s/n 0W650000 and above). Includes
8M0142265 fuel/paddle harness, 6 pin adapter, male bullet insulator and terminals.
Optional kit for to report oil level status to be used in conjunction with SmartCraft BOAT HARNESS - FUEL/PADDLE
gauges or displays.
Feature comes standard on 4.6L V8 Verado AMS. Can be added to 3.4L V6 and
4.8L V8 engines that do not have this feature. Oil level status can be viewed on
VesselViews and SmartCraft gauges.
DIGITAL BLOCK WATER PRESSURE SENSOR

84-8M0075945
6‑Pin male harness connects tanks and paddle wheel to SmartCraft system
For all Verado and 2006 and newer SmartCraft compatible outboard engines 75
HP and above. Also fits MCM/MIE engines (s/n 0W650000 and above).
BOAT HARNESS ADAPTER
71-8M0142696
Optional kit to add digital block water pressure to the SmartCraft data stream
Applicable to the non‑DTS 3.4L V6 and 4.6L V8 engines (DTS versions have this
sensor as standard)

84-898285T01
Needed in order to adapt newer engines that are equipped with a female 6‑pin
connector to a 6‑pin female boat harness.
