DIESEL RIGGING

TDI 3.0L 260 HP ENGINE ASSEMBLY KIT - MECH MERCURY DIESEL TDI ENGINE HARNESS - ENGINE TO
INBOARD VAA
98-8M0078886 2299.98
Engine Assembly Kit includes‑ Literature Kit, Vessel Adapter Assembly,
Vessel Sensor Harness, Drive Application Harness and Gear Actuation
Harness. Must be used with the correct engine during installation
Mercury Diesel TDI 3.0L 260 HP Mechanical Inboard
TDI 4.2L 335 HP ENGINE ASSEMBLY KIT - MECH
INBOARD
98-8M0087265 3374.36
Engine Assembly Kit includes‑ Literature Kit, Vessel Adapter Assembly,
Vessel Sensor Harness, Drive Application Harness and Gear Actuation
Harness. Must be used with the correct engine during installation
Mercury Diesel TDI 4.2L 335 HP Mechanical Inboard
84-8M0066846 173.15
TDI 4.2L 370 HP ENGINE ASSEMBLY KIT - MECH 2 meter engine to VAA harness
INBOARD Mercury Diesel TDI 3.0L and 4.2L Engines
90-8M0087264 3374.36
Engine Assembly Kit includes‑ Literature Kit, Vessel Adapter Assembly, 8M0066847 152.30
Vessel Sensor Harness, Drive Application Harness and Gear Actuation 3 meter engine to VAA harness
Harness. Must be used with the correct engine during installation Mercury Diesel TDI 3.0L and 4.2L Engines
Mercury Diesel TDI 4.2L 370 HO Mechanical Inboard 8M0066848 288.30
TDI 3.0L 235/260 HP ENGINE BOBTAIL KIT - 4 meter engine to VAA harness
MECHANICAL Mercury Diesel TDI 3.0L and 4.2L Engines
98-8M0105427 1677.40 MERCURY DIESEL TDI MECHANICAL JOHNNY
BOBTAIL Kit includes ‑ Literature Kit, Vessel Adapter Assembly, Engine THROTTLE EXTENSION HARNESS
Harness, Engine Cover/Decals and Racor Fuel Pump/Harness Kit. Must
be used with the correct engine during installation
Mercury Diesel TDI 3.0L 235/260 HP engine BOBTAIL ‑ Mechanical and J1939
TDI 4.2L 335/370 HP ENGINE BOBTAIL KIT -
MECHANICAL
98-8M0105425 3376.02
BOBTAIL Kit includes ‑ Literature Kit, Vessel Adapter Assembly, Engine
Harness, Engine Cover/Decals and Racor Fuel Pump/Harness Kit. Must
be used with the correct engine during installation
Mercury Diesel TDI 4.2L 335/370 HP engine BOBTAIL ‑ Mechanical and J1939
MERCURY DIESEL TDI STERNDRIVE HARNESS KIT
8M0099152 437.39 15.45
84-8M0079850
Kit to simplify ordering engine rigging components specific to a TDI Extension harness ‑ Throttle Mechanical ‑ 10 ft
Sterndrive application ‑ contains a 3 meter engine to VAA harness, 20 foot
engine unswitched power harness, 10 foot vessel sensor extension Mercury Diesel TDI 3.0L and 4.2L Diesels, inlcuded in the mechanical engine
harness, fuel level harness, 10 foot trim pump/sender extension harness, a assembly kit
diagnostic port and a 3 foot diagnostic yellow CAN cable. Does not include helm 84-8M0079851 19.57
rigging (control, harnessing, gauges, etc). Extension harness ‑ Throttle Mechanical ‑ 20 ft
Can be used on all Mercury Diesel TDI sterndrive packages.
Mercury Diesel TDI 3.0L and 4.2L Diesels, inlcuded in the mechanical engine
MERCURY DIESEL TDI INBOARD HARNESS KIT assembly kit
MERCURY DIESEL TDI LIFT PUMP HARNESS
EXTENSION

8M0099154 520.35
Kit to simplify ordering engine rigging components specific to a TDI Inboard
application ‑ contains a 3 meter engine to VAA harness, 20 foot engine 84-8M0079847 36.94
unswitched power harness, 10 foot vessel sensor extension harness, fuel
level harness, 10 foot drive application extension harness, a diagnostic port and a Extension Harness, 20 ft.
3 foot diagnostic yellow CAN cable. Does not include helm rigging (control, Used in conjunction with off engine Racor lift pump, included in mechanical engine
harnessing, gauges, etc). assembly kits
DIESEL RIGGING
Can be used on all Mercury Diesel TDI inboard packages.
