INSTALLATION SPECIFICATIONS AND TOOLS ALIGNMENT SHAFT
INSTALLATION SPECIFICATIONS AND TOOLS

ENGINE MOUNTING FIXTURE

91-8M0070098
91-8M0114831
Primary mount assembly. To be used in conjuction with Mount Fixture 22.5 in.(571
mm) p/n 8M0114832 and/or Mount Fixture 25.2 in.(640 mm) p/n 8M0114833 950.00 For MerCruiser drives used with the 4.2L TDI engines 141.10
91-8M0114829
207.80
For use with all Mercury high speed diesel engines For MerCruiser 4.2L TDI engines with ITS transoms
ENGINE MOUNTING FIXTURE ALIGNMENT SHAFT

91-8M0114832 297.35 91-8M2001017 69.85
Fixture mount assembly. To be used in conjuction with Primary Mount Assemby p/n For MerCruiser Vazer drives
8M0114831
For use with all Mercury high speed diesel engines, except the V8 TDI PRELIMINARY SHIFT ADJUSTMENT TOOL
ENGINE MOUNTING FIXTURE

91- 12427T 5.80
Attaches over the shift cable, and aids in proper shift cable
adjustment at the shift plate.
For MCM Bravo One and Bravo Two models.
CENTER LIFTING EYE

91-8M0114833 257.75
Fixture mount assembly. To be used in conjuction with Primary Mount Assemby p/n
8M0114831
For use with Mercury high speed V8 TDI diesel engines
ALIGNMENT SHAFT

863678 20.40
Fits MCM/MIE D1.7L DTI diesel engines.

91-805475A 1 102.45
For MerCruiser drives, except Vazer drives
