BRAVO GIMBAL RING CONVERSION KIT M8 DRIVES

GIMBAL RING KIT TRIM HOSE EXTENSION KIT

8M0061384 1275.45 8M8027354 189.09
Used to convert standard Bravo gimbal ring to heavy duty gimbal ring and bell Set of two 96 inch hoses with 90 degree bend at one end.
housings. Trim limit switch cannot be used on HD gimbal ring. For use with the common M series transom plates and M8 or NXT1 stern drives.
Fits MCM Bravo drives
M8 PROP AERATOR KIT
DRIVESHAFT ASSEMBLY

DRIVESHAFT ASSEMBLY

8M8027372 211.34
Needed on certain boat hulls to ventilate the propellor(s) and reduce time to plane.
Race M8 stern drives.
45-847633A 1 598.37
9 in.(229 mm) 1480 series heavy duty driveline. Adapter may be required for M8 DRIVE CHART
transmission.
Fits Mercury Racing VI and VII stern drives. For use with M series close couple or driveline transom plates
M SERIES TRANSOM PLATE ASSEMBLIES M8 Drive Chart
RACING M SERIES COMMON TRANSOM PLATE ASSEMBLY Ratio Rotation Part Number

5-5V15E40IH
1.245:1
L.H.
6-6M29102IH 1.245:1 R.H. 5-5V25E40IH
Complete common transom plate. When used with older transmissions (72C style) 1.304:1 L.H. 5-5V15X40IH
the 8M8026029 tailstock kit will also be required. Drive line installations may
require additional components not included with this transom plate. 1.304:1 R.H. 5-5V25X40IH
For use with NXT1 LS, NXT1 or SIX SSM and M8 stern drives. 1.334:1 L.H. 5-5V15H40IH
1.334:1 R.H. 5-5V25H40IH
1.398:1 L.H. 5-5V15G40IH
1.398:1 R.H. 5-5V25G40IH
1.461:1 L.H. 5-5V15F40IH
1.461:1 R.H. 5-5V25F40IH
1.531:1 L.H. 5-5V15L40IH
1.531:1 R.H. 5-5V25L40IH
1.692:1 L.H. 5-5V15P40HH
1.692:1 R.H. 5-5V25P40HH
