Page 667 - OEM RIGGING AND ACCESSORIES GUIDE (US-2017)

RACING

ANALOG GAUGE INTERFACE (AGI) KIT
EXTENSION (WING) PLATES
OUTER EXTENSION (WING) PLATE

892486K07 118.73
Includes AGI Module Assembly, Harness and hardware.
For installations using analog gauges instead of SmartCraft. Use with analog
tachometer, coolant temp, oil pressure or level, trim and fuel level. 844342 47.22
Race MerCruiser or outboard engines in single or multiple engine installations plus Bolt on outer wing plate for driveline or close couple engine installations. Mounting
MerCruiser 496Mag/Mag HO engines. hardware is shipped with the engines.
Mercury Branded Racing MerCruiser engines with universal engine mounts.
ANALOG GAUGE INTERFACE (AGI) KIT INNER EXTENSION (WING) PLATE

892486K04 113.48 8M0012221 47.22
For installations using analog gauges instead of SmartCraft. Use with analog Bolt on inner wing plate for driveline or close couple engine installations. Mounting
tachometer,coolant temp, oil temp, oil pressure or fuel pressure gauges. hardware is shipped with the engines.
Race MerCruiser engines with the 14 pin Deutsch connector engine wiring Racing MerCruiser engines with universal engine mounts.
harness. One AGI kit per engine required.
SINGLE EXTENSION (WING) PLATE
VESSEL ANALOG GAUGE INTERFACE (AGI) KIT

RACING

8M0051209 65.91
892486K05 113.48 Bolt on inner wing plate for driveline or close couple engine installations. Mounting
For installations using analog gauges instead of SmartCraft. Use with analog tab hardware is shipped with the engines.
position (port & starboard), fuel level (two fuel tanks) and trim position gauges. Racing MerCruiser engines with universal engine mounts.
Race MerCruiser engines with the 14 pin Deutsch connector engine wiring
harness. One AGI kit per boat required.
