Page 666 - OEM RIGGING AND ACCESSORIES GUIDE (US-2017)

RACING

DRY SUMP SIX/NXT6 SSM SPACER KIT HP RIGGING KITS (14 PIN)

SIX SSM SPACER KIT

8M8024583 1075.04
Triple engine application. Includes all the necessary CAN harnesses & hardware
to connect the engines PCM with the dash/helm area, including key/start function,
846743A 1 869.10 lanyard switch, SmartCraft junction block, & accessory dash power.
.50 inch (12.7 mm) spacer Designed for use with non‑DTS engines using 14 pin "Deutsche" connections at
846562A 1 970.80 the engine harness.
1 inch (25.4 mm) spacer HP RIGGING KITS (14 PIN)
846563A 1 1016.82
1.50 inch (38.1 mm) spacer
846744A 1 1105.08
2 inch (50.8 mm) spacer
846745A 1 1245.17
2.50 inch (63.5 mm) spacer
846564A 1 1335.29
3 inch (76.2 mm) spacer
ENGINE HARNESS RIGGING KITS-NON DTS
8M8024584 1413.81
HP RIGGING KITS (14 PIN)
Quad engine application. Includes all the necessary CAN harnesses & hardware
to connect the engines PCM with the dash/helm area, including key/start function,
lanyard switch, SmartCraft junction block, & accessory dash power.
Designed for use with non‑DTS engines using 14 pin "Deutsche" connections at
the engine harness.
FUEL TANK HARNESS

8M8024581 371.11
Single engine application. Includes all the necessary CAN harnesses & hardware RACING
to connect the engines PCM with the dash/helm area, including key/start function,
lanyard switch, SmartCraft junction block, & accessory dash power.
Designed for use with non‑DTS engines using 14 pin "Deutsche" connections at
the engine harness.
84-898289T75 14.10
HP RIGGING KITS (14 PIN)
120 inch Harness needed to connect tank senders to the 350 Verado SCI and
sterndrive models 565 through 1650
84-898289T75 14.10
120 inch Harness needed to connect tank senders to the 350 Verado SCI and
sterndrive models 565 through 1650

8M8024582 780.33
Twin engine application. Includes all the necessary CAN harnesses & hardware to
connect the engines PCM with the dash/helm area, including key/start function,
lanyard switch, SmartCraft junction block, & accessory dash power.
Designed for use with non‑DTS engines using 14 pin "Deutsche" connections at
the engine harness.

OEM Rigging & Accessories Guide & Price List 653
