RACING

QC4V ENGINES POWER STEERING RESERVOIR CAP

NON-POWER STEERING ADAPTER KIT

8M8020356 52.21
With threads to fit a ‑8 ORB fitting. Allows engines to be rigged with a series return
line, or with the use of two power steering caps a common boat reservoir can be
8M8026006 289.23 added between the two engine mounted reservoirs.
Eliminates the power steering pump from the engine. With the adapter and pulley Gen. 1 525 EFI and 600 SCI engines. All 700 SCI engines.
from the kit installed, the drive belt is re‑used in its original routing.
Mercury Racing QC4v 1100 and 1350 hp engines. POWER STEERING RESERVOIR KIT
CARBON FIBER DRESS KIT

8M8026004 813.60
External power steering reservoir. For use in applications where a common
8M8026070 2731.63 reservoir is wanted or needed. Comes with two inlet ports and two outlet ports plus
Cosmetic upgrade kit. Includes front cover, port and starboard air intake covers an integral bracket that is suitable for mounting to a vertical surface.
plus installation hardware. For use with all Race 525, 600, 662, 700, 850, 1025, 1075, 1200 and QC4v 1100
Race QC4v 1100 engines only. Kit comes standard on 1350 engines. or 1350 engines.
POWER STEERING RACE DTS ACCESSORIES

POWER VALUE BLOCK ASSEMBLY DUAL CALIBRATION TDS KIT RACING

844399T01 499.45 8M0111476 758.19
Used to connect the power steering pump on the engine(s) with the steering helm Theft Deterrent System for Dual Calibration Mercury Racing 1550 engines.
and the steering cylinders located on the drive(s). Includes air purge One kit required per boat. The silver FOB runs the engine on the 1350 mode while
bleeder‑check valves and pressure relief valves. the blue FOB runs the engine in the 1550 mode.
NXT1, NXT1/SSM or Dry Sump Six sterndrives.

OEM Rigging & Accessories Guide & Price List 659
