Page 138 - Rigging and Accessories Guide (2022) - 8M0187689

JOYSTICK RIGGING

BOW THRUSTER ASSEMBLY THRUSTER POWER TO BATTERY CABLE- 20 FEET

8M4510397 2438.15 84-8M0174061 56.58
Joystick piloting outboard bow thruster assembly for single‑engine Thruster to Battery cable, red, 20 feet.
pontoons.
THRUSTER POWER TO BATTERY CABLE- 30
STERN THRUSTER TOP ASSEMBLY W/O COVER FEET

8M4509077 1849.71 84-8M0174062 61.78
Joystick piloting outboard stern thruster assembly for single‑engine Thruster to Batter cable, red, 30 feet.
pontoons. Stern thruster top assembly without cover.
THRUSTER CABLE- 10 FEET
STERN THRUSTER COWL

84-8M0174063 17.41
8M0180132 304.29 Thruster cable, 10 feet.
Joystick piloting outboard stern thruster cowl for single‑engine pontoons.
THRUSTER CABLE- 15 FEET
STERN DATA CABLE- 15 FEET JOYSTICK RIGGING

84-8M0174064 20.01
84-8M0174052 30.56 Thruster cable, 15 feet.
10 pin CANH Stern Data Cable, 15 feet.
THRUSTER CABLE- 20 FEET
STERN DATA CABLE- 20 FEET

84-8M0174065 22.61
84-8M0174053 37.27 Thruster cable, 20 feet.
10 pin CANH Stern Data Cable, 20 feet.
BATTERY CABLE- 30 FEET
STERN DATA CABLE- 30 FEET

84-8M0189596 24.13
84-8M0174054 50.68 Battery cable, 30 feet.
10 pin CANH Stern Data Cable harness, 30 feet
JOYSTICK LINK CABLE - 26 INCH CENTERS
THRUSTER POWER TO BATTERY CABLE- 10
FEET

84-8M0174059 51.38
Thruster power to battery cable, red, 10 feet.
THRUSTER POWER TO BATTERY CABLE- 15
FEET

8M0077126 82.25
Link cable to be used on outboard joystick applications to ensure
prevention of engines contacting each other. This item includes a 27 inch
84-8M0174060 53.98 cable, which is to be used with engines mounted at a 26 inch center
Thruster to Battery cable, red, 15 feet. distance.
Mercury Joystick Piloting for Outboards, with engines mounted on 26 inch centers.
JOYSTICK LINK CABLE - 27 INCH CENTERS
8M0077129 80.08
Link cable to be used on outboard joystick applications to ensure
prevention of engines contacting each other. This item includes a 28 inch
cable, which is to be used with engines mounted at a 27 inch center
distance.
Mercury Joystick Piloting for Outboards, with engines mounted on 27 inch centers.

2022 OEM Rigging & Accessories Guide & Price List 125
