SMARTCRAFT RIGGING

SMARTCRAFT K-PLANES - HARNESSES 84-898059T30 165.93
Tab extension, 30 feet.
Used to extend the harness included with Digital Trim Tabs to plug directly
TRIM TAB INTERFACE KIT into the harness included with SystemView Race Edition. REQUIRED for
all installations with Digital Tabs and SystemView Race Edition EXCEPT Mercury
Racing Sterndrives with New Style 14‑Pin Engine Harness connector. SMARTCRAFT RIGGING

8M0100069 260.13
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Shows digital K‑Plane trim on SmartCraft Instrumentation.
For use with digital K‑Planes and SmartCraft Instrumentation.
K-PLANE Y HARNESS

84-895820T02 146.30
K‑Plane Tab Y harness for dual tabs.
Harness from bullet tab sensor to 4 pin tab interface.
HARNESS ASSEMBLY

84-898059T15 102.63
Tab extension, 15 feet.
Used to extend the harness included with Digital Trim Tabs to plug directly
into the harness included with SystemView Race Edition. REQUIRED for
all installations with Digital Tabs and SystemView Race Edition EXCEPT Mercury
Racing Sterndrives with New Style 14‑Pin Engine Harness connector.
84-898059T20 111.73
Tab extension, 20 feet.
Used to extend the harness included with Digital Trim Tabs to plug directly
into the harness included with SystemView Race Edition. REQUIRED for
all installations with Digital Tabs and SystemView Race Edition EXCEPT Mercury
Racing Sterndrives with New Style 14‑Pin Engine Harness connector.
84-898059T25 143.87
Tab extension, 25 feet.
Used to extend the harness included with Digital Trim Tabs to plug directly
into the harness included with SystemView Race Edition. REQUIRED for
all installations with Digital Tabs and SystemView Race Edition EXCEPT Mercury
Racing Sterndrives with New Style 14‑Pin Engine Harness connector.

2022 OEM Rigging & Accessories Guide & Price List 175
