ELECTRICAL

INSTRUMENT EXTENSION HARNESSES (GAS 14 PIN DATA HARNESSES
ENGINES)
EXTENSION HARNESS - 14 PIN
Fits 1986 and newer MCM/MIE gasoline engines.
INSTRUMENT EXTENSION HARNESS

84-892451T06 55.91
6 ft. (1.8 meter) data harness. Provides data link between DTS engines
and Next Gen DTS remote control harnesses.
Works with all engines equipped with 14‑pin connectors.
84-812441A10 49.10 84-892451T10 65.16
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov 10 ft. (3.0 meter) data harness. Provides data link between DTS engines
10 ft.(3.05 m) harness, 9 lead harness. and Next Gen DTS remote control harnesses.
Used as harness extension or to complete two station installations. Works with all engines equipped with 14‑pin connectors.
84-812441A15 54.58 84-892451T15 100.76
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov 15 ft. (4.6 meter) data harness. Provides data link between DTS engines
15 ft.(4.57 m) harness, 9 lead harness. and Next Gen DTS remote control harnesses.
Used as harness extension or to complete two station installations. Works with all engines equipped with 14‑pin connectors. ELECTRICAL
84-812441A20 62.28 84-892451T20 125.05
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov 20 ft. (6.1 meter) data harness. Provides data link between DTS engines
and Next Gen DTS remote control harnesses.
20 ft.(6.1 m) harness, 9 lead harness.
Used as harness extension or to complete two station installations. Works with all engines equipped with 14‑pin connectors.
84-892451B20 105.72
20 ft. (6.1 meter) data harness. Provides data link between DTS engines
and Next Gen DTS remote control harnesses.
INSTRUMENT EXTENSION HARNESSES (DIESEL) Bulk Pack ‑ 6 harnesses to a box.
Works with all engines equipped with 14‑pin connectors.
Priced individually, sold @ multiples of 6
All 1994‑2000 MCM/MIE diesel models (except D‑Tronic models)
require both an 8 lead and a 9 lead extension harness to connect 84-892451T25 131.21
instumentation to the engine. 25 ft. (7.6 meter) data harness. Provides data link between DTS engines
and Next Gen DTS remote control harnesses.
INSTRUMENT EXTENSION HARNESS Works with all engines equipped with 14‑pin connectors.
84-892451T30 146.38
30 ft. (9.1 meter) data harness. Provides data link between DTS engines
and Next Gen DTS remote control harnesses.
Works with all engines equipped with 14‑pin connectors.
EXTENSION HARNESS - 14 PIN

84-8M0149640 133.66
35 ft. (10.7 meter) data harness. Provides data link between DTS engines
84-860616002 266.18 and DTS Next Gen remote control harnesses.
8 m (26.3 ft.) harness, 21 pin Deutsch connector Works with all engines equipped with 14‑pin connectors.
Fits MCM/MIE D1.7L ; also 2001 and newer D4.2L, D2.8L and 4.2L ES & 14 PIN DATA HARNESS
EI diesel models; also fits 1997 and newer D7.3L Electronic diesel models
DC / DC CONVERTOR EXT. - DIESEL

84-8M0165565 10.20
DC / DC CONVERTOR EXT. ‑ DIESEL

84-8M0146749 222.04
40 foot 14‑pin Low Loss Data Harness
All 14 Pin Engines
