INSTALLATION SPECIFICATIONS AND TOOLS

OUTBOARD ENGINE LIFTING EYE TOOL- DRIVE ALIGNMENT

91-8M0169135 235.75
Outboard 1" and 1.2" prop shaft alignment tool for multiple engine applications. INSTALLATION SPECIFICATIONS AND TOOLS
Order qty. 2 required
TOOL- SERVICE HARNESS

91- 90455 1 34.70
Threads into the flywheel to remove the power head assembly from the driveshaft 91-892333 20.55
housing, or to lift entire engine for removal/installation. WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Fits most 2 cycle Mercury/Mariner Outboards from the 30/40 (2 cyl.) on up. Fuel Circuit Board
LIFTING EYE/FLYWHEEL PULLER LICENSE KEY-G3

8M0179828 213.85
License only, 2018 version
GEARCASE HEIGHT TOOL KIT

91-895343T02 304.25 91-8M0130705 579.20
A combination tool utilized for both lifting the engine and for pulling the flywheel. Engine and gearcase height measurement tool.
Fits the 75‑115 hp. FourStroke outboards (s/n 1B366823 and above), 135‑400 hp. Measures engine (gearcase) height in reference to the boat bottom.
Verado outboards and the F150 EFI FourStroke outboard. Verado 400R outboard.
All engine gearcase types.
ALIGNMENT TOOL LIFTING STRAP

91-8M0180314 249.95
New V12 dual prop shaft alignment tool. Multiple engine applications. Must order
min. quantity 2.
DRIVE ALIGNMENT TOOL

91-883705T01 144.35
GW Lifting strap v6/v8
An engine lifting strap for handling of the 225 EFI and the "NEW" V6 (3.4L) and V8
(4.6L) FourStroke outboards

91-8M0029055 326.45
Used with Axius, Zeus, JPS and MerCruiser electric steering to align the drives
with the boat. Two pieces required for alignment. Also compatible with Bravo 3
tiebar

2022 OEM Rigging & Accessories Guide & Price List 279
