INSTALLATION SPECIFICATIONS AND TOOLS
INSTALLATION SPECIFICATIONS AND TOOLS INSTALLATION AIDS TOOL KIT-DIAG G3 803.40
INSTALLATION SPECIFICATIONS AND TOOLS

14 PIN BRACKET

91-8M0168921
Full kit with license, harnesses, and kvaser cable
TRANSOM DRILLING FIXTURE KIT - PROFESSIONAL
OPTION

8M0076435 6.35
Rounded edges and anti‑rotation
Rigging aid for 14 pin data cable
NUT
91-8M0138402 1132.10
Kit includes: Suction cup for a seriously good hold for accurate drilling, suction cup
manual & cover, 2" drill guide blocks that ensure straight drill path for thick
transoms and 2 holes per guide block that reduces the likelihood of drilling into the
wrong hole.
Fits: L4 and L6 Verado, 175‑300 HP V6 (3.4L) & V8 (4.6L), 150 HP FourStroke &
75‑115 HP (2.1L) EFI FourStroke engines.
TRANSOM DRILLING FIXTURE - STANDARD

11-889664 3.20
(1.500‑18) Black Nylon
91-8M0149520 646.50
BOAT HARNESS ADAPTER Only includes the drill fixture, standard 20 hole, 1" block.
Fits: L4 and L6 Verado, 175‑300 HP V6 (3.4L) & V8 (4.6L), 150 HP FourStroke &
75‑115 HP (2.1L) EFI FourStroke engines.
DRILL GUIDE BLOCK - OEM 2 INCH

84-898285T01 9.24
Needed in order to adapt newer engines that are equipped with a female 6‑pin
connector to a 6‑pin female boat harness.
DUAL STATION RIG HARNESS 91-8M0149527 143.50
2‑Inch drill guide block with 2 holes.
Profession option for OEM boat builders (utilize on new / undrilled transoms to
ensure thick transoms are drilled straight).
DRILL GUIDE BLOCK - 2 INCH

91-8M0149526
2‑Inch drill guide block with 5 holes
Professional option (use on thick transoms to ensure straight drill path).
91-8M0119480 34.37
Kit contains one harness and two weather caps
Used to temporarily rig a second station such that the vessel can be operated while
the second station is not installed (shipping, rigging installation, short term rework,
etc). Not compatible with sf2 next gen DTS.
