Page 580 - Rigging and Accessories Guide (2022) - 8M0187689

OUTBOARD

REMOTE 3.0 US GAL (11 L) OIL TANK OIL TANK HOSE EXTENSION

1257- 8742A23 254.85 41729A 3 110.10
Remote 3.0 US gal (11 L) Oil Tank without sender, complete with tank, Includes 30 ft. (9.14 m) of double barrel hose and 4 tie straps.
lines, mounting bracket and all hardware. Old Bracket Design Can be used with either remote oil reservoir tank which requires a longer hose due
Optional tank size for Mercury/Mariner 2 cycle outboards, to be used to location.
wherever a pressurized oil reservoir system is already in use. This tank and
bracket assembly may be optionally floor or wall mounted.
DECK OIL FILL KIT
OIL TANK HOLD DOWN KIT
Allows filling remote oil reservoirs from deck mounted filler pipe.

DECK FILL KIT - OIL (STRAIGHT ELBOW) OUTBOARD

12335A 1 58.90
With bracket, strap and hardware.
Fits the 3.0 gallon (11 L) remote oil reservoir tank. This optional bracket may be
either floor or wall mounted as desired.
15969A 3 39.95
OIL TANK HOLD DOWN KIT Complete with deck fittings, 4 ft. (1.22 m) fill hose, filler cap and necessary
mounting hardware.
For use with 1.8 US gal (6.8 L) or 3 US gal (11 L) remote oil tank reservoirs. This
kit must NOT be used with Auto Blend.
DECK FILL KIT - OIL (80 DEGREE ELBOW)

884481A 1 52.75
With floor bracket, strap and hardware.
Fits the 3.0 gallon (11 L) remote oil reservoir tank. Bracket may only be used as a
floor mounted application.
OIL TANK HOLD DOWN KIT 15969A06 52.95
Complete with deck fittings, 4 ft. (1.22 m) fill hose, filler cap and necessary
mounting hardware.
For use with 1.8 US gal (6.8 L) or 3 US gal (11 L) remote oil tank reservoirs. This
kit must NOT be used with Auto Blend.
REPLACEMENT TANK ADAPTER

824954A 1 51.90
With bracket, strap and hardware.
Fits the 1.8 gallon (6.8 L) remote oil reservoir tank.

15967 29.75
For use with 1.8 US gal (6.8 L) or 3 US gal (11 L) remote oil tank reservoirs. This
kit must NOT be used with Auto Blend.
2022 OEM Rigging & Accessories Guide & Price List 567
