X-HAUST TRANSOM DRILL FIXTURE NXT1 DRIVELINE KIT
NXT TRANSMISSION DRIVELINE KIT
91-8M0036608 1473.95
X‑Haust installation tool
For use on 600 SCi, EU662 SCi and 700 SCi engines.
842064A02 3504.63
X-HAUST TRANSOM DRILL FIXTURE WARNING: Cancer - www.P65Warnings.ca.gov
For conversion of a close couple 700SCi to a driveline engine .
Racing sterndrive packages with the NXT transmission only.
NXT1 STEERING INDICATOR
STEERING POSITION INDICATOR KIT
91-8M0064794 1519.00
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
X‑Haust installation tool
For use on 540 and 565 engines.
NXT1 / SIX SSM DRIVE CHART
8M8021162 284.16
For use with M series close couple or driveline transom plates. Provides steering position indication.
For use with the Race NXT1 drive only. Compatible with SmartCraft SC1000
NXT SSM Drive Chart gauges, SC5000 Systemview and Systemview Race Edition.
NXT1 WATER PICKUP KITS
Ratio Rotation Part Number
1.15:1 L.H. 5-5R15W20HH
WATER PICK UP KIT
1.15:1 R.H. 5-5R25W20HH
1.24:1 L.H. 5-5R15E20HH
1.24:1 R.H. 5-5R25E20HH
1.30:1 L.H. 5-5R15X20HH
1.30:1 R.H. 5-5R25X20HH
1.35:1 L.H 5-5R15H20HH
1.35:1 R.H. 5-5R25H20HH
1.42:1 L.H. 5-5R15J20HH
1.42:1 R.H. 5-5R25J20HH
1.50:1 L.H. 5-5R15K20HH
842049A01 703.09
1.50:1 R.H. 5-5R25K20HH
WARNING: Cancer - www.P65Warnings.ca.gov
1.61:1 L.H. 5-5R15N20HH (0.1 square inch)
1.61:1 R.H. 5-5R25N20HH Interchangeable water pick up. For boat speed of 150 to 200 mph.
Race NXT1 sterndrives. One kit per drive required.
1.69:1 L.H. 5-5R15P20HH
842049A02 703.09
1.69:1 R.H. 5-5R25P20HH
WARNING: Cancer - www.P65Warnings.ca.gov
(0.2 square inch)
Interchangeable water pick up. For boat speed of 110 to 160 mph.
Race NXT1 sterndrives. One kit per drive required.
RACING 842049A03 703.09
WARNING: Cancer - www.P65Warnings.ca.gov
(0.3 square inch)
Interchangeable water pick up. For boat speed of 90 to 130 mph.
Race NXT1 sterndrives. One kit per drive required.
