ANALOG INSTRUMENTS

ANALOG GAUGE INTERFACE ANALOG GAUGE INTERFACE KIT

DTS ENGINE - ANALOG GAUGE HARNESS

84-8M0150539 8.07
An analog gauge harness (3 feet) specific for DTS engines that is more
cost effective than the AGI (Analog Gauge Interface) solution
Compatible with DTS, outboard, and V6/ V8 engines
DTS ENGINE - ANALOG GAUGE HARNESS 892486K08 100.53
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Used on 14‑pin engines to convert a digital sensor signal into analog for
Tachometer, Oil Pressure/Oil Level, Water Temperature, Trim, and Fuel
Level analog gauges. There is also a connection for SC100 Link Gauges.
Enhanced Voltage Suppression.
Used with a 10 Pin Junction Box connection, For Non‑PCM09 ECUs ‑ Fits
SmartCraft compatible 14‑pin engines
8M0109742 99.90
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Used on 14‑pin engines to convert a digital sensor signal into analog for
Tachometer, Oil Pressure/Oil Level, Water Temperature, Trim, and Fuel
Level analog gauges. There is also a connection for SC100 Link Gauges.
84-8M0095716 16.92 No Voltage Suppression.
An analog gauge harness (15 feet) specific for DTS engines that is more cost Used with a 10 Pin Junction Box connection. For PCM09 ECUs only ‑ Fits ANALOG INSTRUMENTS
effective than the AGI (Analog Gauge Interface) solution SmartCraft compatible 14‑pin engines.
Compatible with DTS, outboard, and V6/ V8 engines ANALOG GAUGE INTERFACE (AGI) KIT
84-8M0095826 20.59
An analog gauge harness (20 feet) specific for DTS engines that is more cost
effective than the AGI (Analog Gauge Interface) solution
Compatible with DTS, outboard, and V6/ V8 engines
84-8M0095827 23.49
An analog gauge harness (25 feet) specific for DTS engines that is more cost
effective than the AGI (Analog Gauge Interface) solution
Compatible with DTS, outboard, and V6/ V8 engines
84-8M0095828 25.13
An analog gauge harness (30 feet) specific for DTS engines that is more cost
effective than the AGI (Analog Gauge Interface) solution
Compatible with DTS, outboard, and V6/ V8 engines
892486K07 142.44
EXTENSION HARNESS- 17 FT
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Includes AGI Module Assembly, Harness and hardware.
For installations using analog gauges instead of SmartCraft. Use with analog
tachometer, coolant temp, oil pressure or level, trim and fuel level. Enhanced
Voltage Suppression.
84-8M0150477 19.60 Race MerCruiser or outboard engines in single or multiple engine installations plus
Analog gauge harness to 4pin 3ft and 17ft extension (20 ft). Enhanced Voltage MerCruiser 496Mag/Mag HO engines.
suppression. Compatible with OB, DTS, V6/V8.
ANALOG GAUGE INTERFACE (AGI) KIT
HARNESS EXTENSION- 27 FT

84-8M0150478 26.38
Analog gauge harness to 4pin 3ft and 27ft extension (30ft). Enhanced Voltage
suppression. Compatible with OB, DTS, V6/V8.

892486K04 136.14
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
For installations using analog gauges instead of SmartCraft. Use with analog
tachometer,coolant temp, oil temp, oil pressure or fuel pressure gauges. Enhanced
Voltage Suppression.
Race MerCruiser engines with the 14 pin Deutsch connector engine wiring
harness. One AGI kit per engine required.
