MECHANICAL REMOTE CONTROLS

SIDE MOUNT REMOTE CONTROL
MSC 4000 SIDE MOUNT - MANUAL START W/ NO
SWITCH

These controls are for Outboard engines and can be mounted on the
Port or Starboard side. The controls do not include switches or harness.
SIDE MOUNT REMOTE CONTROL

881170A12 217C70 362.83
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
This control features a non ‑ trim handle and a 15 ft. (4.58 M) harness with Amp
connector and will direct connect to the engine models below without the use of an
Adapter harness.
For MY2005 and newer, 8/9.9, 15/20 HP FourStroke Outboards with electric start
and non‑trim.
For MY2005 and newer 8/9.9 FourStroke Outboards SAE T/S cables must be
used. 881170A 8 170C65 284.41
For 8/9.9 FourStroke engines generation change above S/N OR192772 and 15/20 This control is for manual start models.
FourStroke engines will use GEN I cables.
GEN I cables must be used on other engines. Fits Mercury/Mariner 4/5 HP and Mariner 8/55 HP (2 cyl.)
GEN I cables must be used.
MSC 4000 SIDE MOUNT - MANUAL START, W/ MSC 4000 SIDE MOUNT - ACCESSORIES
SWITCH
DUAL ENGINE MOUNT KIT
These controls are for Outboard engines and can be mounted on the
Port or Starboard side. These controls feature an ignition stop switch
and lanyard stop switch only.
SIDE MOUNT REMOTE CONTROL

16909A 2 15C77 26.29
This kit contains all necessary hardware for mounting or stacking two controls
together for dual engine installations.
REMOTE CONTROL SPACER PLATE
881170A 4 214C82 358.03
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov MECHANICAL REMOTE CONTROLS
This control is for manual start models and has a 20 ft.(6.1 m) harness. The control
features a Toggle switch for remote shut off of the engine.
Fits current pull style throttle, manual start Mercury/Mariner 6/25 HP, 30/40 HP (2
cyl.‑ U.S. origin), 40 (3 & 4 cyl.) to 45 HP, 8/9.9, 15/20 HP FourStroke models
(1996 and newer), and Force 25 HP (3 cyl.)
For MY2005 and newer 8/9.9 FourStroke Outboards SAE T/S cables must be
used.
For 8/9.9 FourStroke engines generation change above S/N OR192772 and 15/20
FourStroke engines will use GEN I cables.
GEN I cables must be used on other engines.
881170A 6 224C97 374.96 17063T 7C23 12.06
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov Included with Commander 2000/MSC 4000 side mount control. Generally, one
This control is for manual start models and has a 20 ft.(6.1 m) harness. This control spacer is adequate for most installations: however, two or more can be stacked to
features a push throttle cable operation and a Toggle switch for remote shut off of provide additional side clearance. Measures 1/2 in.(13 mm) thick.
the engine.
Fits older push style throttle Mercury/Mariner 20/25 HP (U.S. S/N 0G044026 and
below; Belgium S/N 9807908 and below) and Force 9.9/15 HP (1997 and older).
