Page 542 - US ACCESSORIES GUIDE (2019)

MECHANICAL REMOTE CONTROLS

SIDE MOUNT REMOTE CONTROL- 8 PIN TRADITIONAL REMOTE CONTROL ADAPTER HARNESS

881170A15 251C88 419.81 84-892473A01 45C15 75.25
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
This control features a handle mounted power trim switch, 15 ft. Converts the traditional Mercury connector to an Amp 8‑pin connector.
(4.58 m) harness, built‑in warning horn and power trim leads for front mount switch. Converts side mount controls 881170A 3, 15, 16 and the 816626A_ series ignition
Fits all current Mercury/Mariner outboards (with integral power trim) and 1993 and keyswitch harness to connect to the MY2005 and newer 8/9.9 hp. FourStroke
newer Force outboards 40 HP and higher utilizing Mercury style cables (with power outboard.
trim). When used with MY2005 and newer 8/9.9/15/20 FourStroke outboards an MY2005 and newer 8/9.9 hp. FourStroke outboard and the 15/20 hp. FourStroke
adapter harness is required. (351cc) outboard when a 8 pin side mount control or keyswitch harness is used.
For MY2005 and newer 8/9.9 FourStroke outboards SAE T/S cables must be used.
GEN I cables must be used. HARNESS EXTENSION- 10 PIN
881170A20 258C13 430.22
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
This control features a handle mounted power trim switch, 20 ft. (6.1 m) harness,
built‑in warning horn and includes power trim leads for front mount switch.
Fits all current Mercury/Mariner outboards (with integral power trim) and 1993 and
newer Force outboards 40 HP and higher utilizing Mercury style cables (with power
trim). When used with MY2005 and newer 8/9.9, 15/20 FourStroke outboards an
adapter harness is required.
For MY2005 and newer 8/9.9 FourStroke outboards SAE T/S cables must be used.
GEN I cables must be used.
SIDE MOUNT REMOTE CONTROL- 10 PIN AMP
84-8M0058668 16C87 28.12
WARNING: Cancer - www.P65Warnings.ca.gov
This harness extension will allow you to increase the length by 6 feet of the 10 pin
drop for instruments. The extension will work with Side Mount controls as well as
any 896537 series main engine / boat harness.
MSC 4000 SIDE MOUNT - ELECT, NON-POWER
TRIM

The 8M0083860 is not "push to choke" and has a 14 pin connector
881170A10 249C00 415.00 wiring harness, lanyard stop, throttle only feature. This control also
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov requires Gen II throttle and shift cables, is starboard mounted and not MECHANICAL REMOTE CONTROLS
This control features a handle mounted power trim switch, 15 ft. (4.58 m) harness stackable.
The remainder of controls 881170A3, 881170A5, 881170A7, 881170A12
with Amp 10‑pin connector. The control will connect to the engine models below
without the use of an adapter. can be mounted starboard or port side and are stackable. They offer
Used on MY2005 and newer, 8/9.9, 15/20 FourStroke engines with electric start "push to choke" ignition switch, 8 pin connector wiring harness, lanyard
and power trim. stop switch, separate neutral warm‑up lever and requires Gen I throttle
For 8/9.9 FourStroke engines generation change above S/N OR192772 and 15/20 and shift cables. All controls have a 5 pin accessory plug for tachometer
FourStroke engines will use GEN I cables. and an adjustable throttle friction. These controls are not for use with
GEN I cables must be used on other engines. engines that have counter rotating lower units. Older engines may
SIDE MOUNT REMOTE CONTROL require an adapter harness.
881170A11 256C46 427.44
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov SIDE MOUNT REMOTE CONTROL- 14 PIN
This control features a handle mounted power trim switch, 20 ft. (6.1 m) harness
with Amp 10‑pin connector. The control will connect to the engine models below
without the use of an adapter harness.
Used on MY2005 and newer, 8/9.9, 15/20 FourStroke engines with electric start
and power trim. 8M0138642 238C91 398.18
For 8/9.9 FourStroke engines generation change above S/N OR192772 and 15/20
FourStroke engines will use GEN I cables. WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
GEN I cables must be used on other engines. This control features non ‑ power trim and a 15ft. (4.58m) harness with 14 pin
Deutsch connector.
Fits all current Mercury/Mariner Outboards 6 HP and above (without power trim),
and 1993 and newer Force Outboards 40 HP and higher utilizing Mercury cables
(without power trim).
When used with a MY2005 and newer 8/9.9, 15/20 FourStroke Outboard an
Adapter harness is required. 2 pin connector is now included to allow for use of
SmartCraft accessories with analog gauges.
Gen II cable must be used.
2019 US Accessories Guide 529
