DIESEL RIGGING

MERCURY DIESEL 2.0L VESSEL INTERFACE PANEL - MERCURY DIESEL SINGLE ENGINE SINGLE HELM
MECH STERNDRIVE (BRAVO) PANEL DTS BOARD

8M0091581 1061.38 84-8M0071357 343.83
Vessel Interface Panel: loaded with software specific to this application. This helm board includes CCM, harness and hardware needed to install
Mercury Diesel 2.0L ‑ Mechanical Sterndrive (Bravo), Tier 3 DTS on single applications.
Mercury Diesel Tier 2: Single engine DTS applications (Inboards and
MERCURY DIESEL VESSEL INTERFACE PANEL - DTS Sterndrives (SC 2.2))
INBOARD
84-8M0070066 842.89 MERCURY DIESEL DUAL ENGINE SECOND HELM
Vessel Inteface Panel: includes a SIM and loaded software for a specific PANEL DTS KIT
engine family. (White Box)
VIP communicates diesel engine data
Mercury Diesel ‑ DTS Inboard (SC 2.2), Tier 2 (2.0L, 2.8L and 4.2L inline engines) 8M0071420 1389.45
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
MERCURY DIESEL VESSEL INTERFACE PANEL - DTS This helm panel kit is used for the second helm station for dual diesel
INBOARD (TROLL) engine applications. It includes the helm board with CCM loaded software,
84-8M0070068 842.89 hardware, harness, start/stop switch and hardware.
Vessel Interface Panel: includes a SIM and loaded software for a specific Mercury Diesel Tier 2: Dual DTS engine (Inboards, Inboards +Troll and Sterndrive ‑
engine family. (White Box) Uses CCM 48)
VIP communicates diesel engine data.
Mercury Diesel ‑ DTS Inboard + Troll (SC 2.2), Tier 2 (2.0L, 2.8L and 4.2L inline MERCURY DIESEL HELM PANEL BOARD - AXIUS GEN II
engines)
MERCURY DIESEL VESSEL INTERFACE PANEL - DTS
STERNDRIVE
84-8M0070069 842.89
Vessel Interface Panel: includes a SIM and loaded software for a specific
engine family. (White Box)
VIP communicates diesel engine data
Mercury Diesel ‑ DTS Sterndrive (SC 2.2), Tier 2 (2.0L, 2.8L and 4.2L inline
engines)
MERCURY DIESEL VESSEL INTERFACE PANEL - AXIUS
GEN II
84-8M0070070 842.89 98-8M3800000 3067.69
Vessel Interface Panel: includes a SIM and loaded software for a specific WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
engine family. (White Box)
VIP communicates diesel engine data This helm board will include CCM's, Harness and Hardware needed to Gen II Axius
on diesle DTS engines (specific application)
Mercury Diesel ‑ Axius Gen II (SC 2.5), Tier 2 (2.0L, 2.8L and 4.2L inline engines)
Mercury Diesel Axius Gen II (SC 2.5) on Tier 2 4.2L engine
MERCURY DIESEL VESSEL INTERFACE PANEL - MECH
INBOARD GENERAL DIESEL RIGGING COMPONENTS
84-8M0070071 842.90
Vessel Interface Panel: includes a SIM and loaded software for a specific MERCURY DIESEL MECHANICAL HELM HARNESS
engine family. (White Box)
VIP communicates diesel engine data
Mercury Diesel ‑ Mechanical Inboard (SC 2.2), Tier 2 (2.0L, 2.8L and 4.2L inline
engines)
MERCURY DIESEL VESSEL INTERFACE PANEL - MECH
STERNDRIVE
84-8M0070072 842.90
Vessel Interface Panel: includes a SIM and loaded software for a specific
engine family. (White Box)
VIP communicates diesel engine data
Mercury Diesel ‑ Mechanical Sterndrive (SC 2.2), Tier 2 (2.0L, 2.8L and 4.2L inline
engines)
84-8M0084296 82.21
Non DTS Helm Harness
Mercury Diesel: Mechanical versions of TDI 3.0L and 4.2L, Tier 2 and Tier
3 (use one per engine at the helm), does not support SmartCraft depth or
steering sensors DIESEL RIGGING
