Page 178 - OEM RIGGING AND ACCESSORIES GUIDE (2021) - 8M0174477

SMARTCRAFT RIGGING

SMARTCRAFT J-BOX TERMINATOR/RESISTOR PLUG ASY DIAGNOSTIC PORT SMARTCRAFT RIGGING

859318T 1 7.58 8M0046339 25.39
SmartCraft Yellow 10‑pin Terminator/Resistor WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Provides CAN Bus termination for CAN P network. 10 pin diagnostic port for use on any SmartCraft application.
859318B 1 7.55 Used as a 10 pin diagnostic port for connecting Mercury Computer
SmartCraft Yellow Junction Box Terminator/Resistor Diagnostic System (CDS) junction box connection. Typically gets mounted
at the helm, out of line of sight so that a technician does not have to disassemble
Provides CAN Bus termination where installed helm to plug into a 10 pin connection. Requires a harness from back of diagnostic
Priced individually, sold @ multiples of 24 port to a 10 pin SmartCraft connection in the rigging.
TERMINATOR ASSEMBLY J-BOX Y HARNESS

84-8M0165555 27.30
J‑BOX Y HARNESS
5-WAY J-BOX KIT W/3 WEATHER CAPS

8M0055652 11.79 98-8M0165557
SmartCraft Red Terminator Can 1/P & H 5‑WAY J‑BOX KIT w/3 WEATHER CAPS
RESISTOR- TERMINATION- 2 PIN 5-WAY J-BOX KIT @ 24 KIT

8M0175293
5‑WAY J‑BOX KIT @ 24 Kit
J-BOX STACKING PLUG KIT

893388A01 7.40 23-8M0174363
Blue 2‑pin terminator/resistor J‑BOX STACKING PLUG KIT. J‑BOX Stacking Plug designed for easily vertical
Provides CAN bus termination for CAN Networks. stackability of J‑Boxes, allows for all plugs to be positioned on one side
HELM MPR 2 PIN WEATHER CAP BLUE CAN P RESISTOR

82-8M0171627 11.19
BLUE CAN P RESISTOR

86-8M0054244 4.29
GT280 2 pin male weather cap.
Used on Joystick (Zeus, Axius and JPO) applications for the Helm MPR connection
harness 8M2021476.

2021 OEM Rigging & Accessories Guide & Price List 165
