ELECTRICAL

INSTRUMENT EXTENSION HARNESSES (DIESEL) HARNESS ADAPTER

All 1994‑2000 MCM/MIE diesel models (except D‑Tronic models)
require both an 8 lead and a 9 lead extension harness to connect
instumentation to the engine.

INSTRUMENT EXTENSION HARNESS

84-860624 49.20
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Adapts engine harness 84‑806389A 2 (used on 1994‑1997 D3.0L, D3.6L and
D4.2L diesel models) to extension harnesses 84‑860615 or 84‑860616.
HARNESS ADAPTER
84-855390 315.10
20 ft.(6 m) harness
Fits (1997‑2000) D2.8L and D4.2L Electronic diesel models
INSTRUMENT EXTENSION HARNESS
ELECTRICAL

84-860625 73.15
WARNING: Cancer - www.P65Warnings.ca.gov
Adapts engine harness 84‑855509 or 84‑803626 (used on 1997 & up D2.8L and
D4.2L ES and EI diesel models) to extension harnesses 84‑860615 or 84‑860616.
21 pin to 17 pin connector
84-860615002 175.00 DC / DC CONVERTOR EXT. - DIESEL
4 m (13.2 ft.) harness, 21 pin Deutsch connector
Fits D1.7L , 2001 and newer D4.2L, D2.8L and 4.2L ES and EI; 1997 and newer
D7.3L ES diesel models.
84-860616002 241.52
8 m (26.3 ft.) harness, 21 pin Deutsch connector 84-8M0165565
Fits MCM/MIE D1.7L ; also 2001 and newer D4.2L, D2.8L and 4.2L ES & DC / DC CONVERTOR EXT. ‑ DIESEL
EI diesel models; also fits 1997 and newer D7.3L Electronic diesel models
14 PIN DATA HARNESSES
HARNESS ADAPTER
EXTENSION HARNESS - 14 PIN

84-860622 49.55
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
21 pin female Deutsche connector to 8 pin & 9 pin female connector 84-892451T06 50.73
Adapts newer diesel engines with 21 pin Deutsch connector engine harnesses to 6 ft. (1.8 meter) data harness. Provides data link between DTS engine and
command module harness.
older diesel engines instrument harness with the 8 pin & 9 pin connectors.
Works with all engines equipped with 14‑pin connectors.
84-892451T10 59.13
10 ft. (3.0 meter) data harness. Provides data link between DTS engine
and command module harness.
Works with all engines equipped with 14‑pin connectors.
84-892451T15 91.43
15 ft. (4.6 meter) data harness. Provides data link between DTS engine
and command module harness.
Works with all engines equipped with 14‑pin connectors.
