SMARTCRAFT RIGGING

3-PIN TANK HARNESS STEERING SENSOR KIT SMARTCRAFT RIGGING

84-864218 14.43 863188A 5 137.18
Fits older MCM/MIE mechanical engines that are equipped with a 3‑pin WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
tank harness connector. Provides steering angle and degrees to SmartCraft instruments so gauge
can display steering position ‑ useful when docking. Includes steering
harness 84‑864219 & 84‑863931
Fits all SmartCraft compatible MerCruiser and Mercury Racing product . Also used
STEERING ANGLE SENSORS on CMD engines

STEERING/SPEEDO SENSOR KIT
SMARTCRAFT K-PLANES - HARNESSES

K-PLANE Y HARNESS

863188A 3 163.13
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Provides steering angle and degrees, and speed to SmartCraft instruments
so gauge can display steering position and speed ‑ useful when docking.
Includes steering/speedo‑pitot harness P/N 84‑863736, required for newer 84-895820T02 130.91
engines that do not have the steering/speedo‑pitot harness included with engine K‑Plane Tab Y harness for dual tabs.
harness. Harness from bullet tab sensor to 4 pin tab interface.
Fits all SmartCraft compatible MerCruiser and Mercury Racing products.
HARNESS ASSEMBLY
STEERING SENSOR KIT

84-898059T15 95.81
863188T 4 107.38
Provides steering angle and degrees to SmartCraft instruments so gauge Tab extension, 15 feet.
can display steering position ‑ useful when docking. Used to extend the harness included with Digital Trim Tabs to plug directly
into the harness included with SystemView Race Edition. REQUIRED for
Fits all SmartCraft compatible MerCruiser and Mercury Racing products. all installations with Digital Tabs and SystemView Race Edition EXCEPT Mercury
Racing Sterndrives with New Style 14‑Pin Engine Harness connector.
84-898059T20 104.31
Tab extension, 20 feet.
Used to extend the harness included with Digital Trim Tabs to plug directly
into the harness included with SystemView Race Edition. REQUIRED for
all installations with Digital Tabs and SystemView Race Edition EXCEPT Mercury
Racing Sterndrives with New Style 14‑Pin Engine Harness connector.
84-898059T25 128.74
Tab extension, 25 feet.
Used to extend the harness included with Digital Trim Tabs to plug directly
into the harness included with SystemView Race Edition. REQUIRED for
all installations with Digital Tabs and SystemView Race Edition EXCEPT Mercury
Racing Sterndrives with New Style 14‑Pin Engine Harness connector.
