ELECTRICAL

84-892451T20 98.96 84-8M0146744 107.80
20 ft. (6.1 meter) data harness. Provides data link between DTS engine Low Loss, All 14 PIN Engine, Data Harness, 15 FEET. Scenarios when
and command module harness. Low Loss cables are required ‑ for harness length where the overall data
Works with all engines equipped with 14‑pin connectors. cable run from engine to helm is 35 FEET or more, all multi‑helm
84-892451B20 95.92 applications, all Joystick piloting and electric steering helm applications, and all
applications with three or more engines
20 ft. (6.1 meter) data harness. Provides data link between DTS engine All 14 Pin Engines
and command module harness.
Bulk Pack ‑ 6 harnesses to a box. 84-8M0146745 125.21
Works with all engines equipped with 14‑pin connectors. Low Loss, All 14 PIN Engine, Data Harness, 20 FEET. Scenarios when
Low Loss cables are required ‑ for harness length where the overall data
Priced individually, sold @ multiples of 6 cable run from engine to helm is 35 FEET or more, all multi‑helm
84-892451T25 106.49 applications, all Joystick piloting and electric steering helm applications, and all
25 ft. (7.6 meter) data harness. Provides data link between DTS engine applications with three or more engines
and command module harness. All 14 Pin Engines
Works with all engines equipped with 14‑pin connectors. 14 PIN DATA HARNESS
84-892451T30 114.02
30 ft. (9.1 meter) data harness. Provides data link between DTS engine
and command module harness.
Works with all engines equipped with 14‑pin connectors.
EXTENSION HARNESS - 14 PIN

84-8M0149640 121.28
35 ft. (10.7 meter) data harness. Provides data link between DTS engine
and command module harness. 84-8M0146746 141.18
Works with all engines equipped with 14‑pin connectors. ELECTRICAL
25 foot 14‑pin Low Loss Data Harness
14 PIN DATA HARNESS All 14 Pin Engines
84-8M0146747 163.75
30 foot 14‑pin Low Loss Data Harness
All 14 Pin Engines
84-8M0146748 183.46
35 foot 14‑pin Low Loss Data Harness
All 14 Pin Engines
84-8M0146749 201.47
40 foot 14‑pin Low Loss Data Harness
All 14 Pin Engines
14 PIN DATA HARNESS
84-8M0146749 201.47
40 foot 14‑pin Low Loss Data Harness
All 14 Pin Engines
14 PIN DATA HARNESS

84-8M0146750 246.27
45 foot 14‑pin Low Loss Data Harness
All 14 Pin Engines
84-8M0146751 259.91
50 foot 14‑pin Low Loss Data Harness
84-8M0146742 66.09 All 14 Pin Engines
Low Loss, All 14 PIN Engines, Data Harness, 5 FEET. Scenarios when 262.73
Low Loss cables are required ‑ for harness length where the overall data 84-8M0146752
cable run from engine to helm is 35 FEET or more, all multi‑helm 55 foot 14‑pin Low Loss Data Harness
applications, all Joystick piloting and electric steering helm applications, and all All 14 Pin Engines
applications with three or more engines 317.49
84-8M0146753
All 14 Pin Engines 60 foot 14‑pin Low Loss Data Harness
84-8M0146743 91.70 All 14 Pin Engines
Low Loss, All 14 PIN Engine, Data Harness, 10 FEET. Scenarios when
Low Loss cables are required ‑ for harness length where the overall data
cable run from engine to helm is 35 FEET or more, all multi‑helm
applications, all Joystick piloting and electric steering helm applications, and all
applications with three or more engines
All 14 Pin Engines

2021 OEM Rigging & Accessories Guide & Price List 187
