P. 230

ELECTRICAL


             TRANSOM MOUNTED POWER TILT PANEL                    POWER TRIM SWITCH KIT












                87-815200A02                             33.70      87- 18286A18                             42.05
                    WARNING: Cancer - www.P65Warnings.ca.gov            WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
             Rocker switch style with 6 ft.(1.8 m) harness and bullet connectors. Provides tilt  Rocker style switch with 10 ft. harness and bullet connectors. Can be surface
             control from the outside of the boat when trailering and launching. "T" harness  mounted or flush mounted. Provides tilt control from the bow or transom location.
             (included in kit) connects directly to trim pump with 3 pin Packard connector.  Fits Mercury/Mariner models equipped with integral trim pump.
             Fits MCM models with newer power trim having the 3 pin Packard connector.
                                                                 POWER TRIM SWITCH KIT
             OUTBOARD POWER TRIM SWITCH KITS

             POWER TRIM SWITCH KIT                                                                                    ELECTRICAL









                                                                    87- 18286A47                             42.04
                                                                        WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
                                                                 Rocker switch style with 10 ft.(3.0 m) harness and bullet connectors. Can be
                                                                 surface mounted or flush mounted. Provides tilt control from the bow or transom
                87- 14645A 4                             93.95   location.
                    WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov  Fits Mercury/Mariner 75‑115 hp. FourStroke outboards beginning with serial
             Toggle switch style. Tiller handle mounted.         number 1B366823‑2B094955.
             Fits Mercury/Mariner 40 JET and 50/60 hp. outboards and operates the power trim  POWER TRIM SWITCH KIT
             kit added to a base ELHO model engine.  See Tiller application chart for specific
             engine models.
             POWER TRIM SWITCH KIT









                                                                    87- 18286A19                             33.20
                                                                        WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
                                                                 Rocker switch style with 25 ft.(7.62 m) harness and bullet connectors. Can be
                87- 18286A17                             41.90   surface mounted or flush mounted. Provides tilt control from the bow or transom
                    WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov  location.
             Rocker switch style with 10 ft.(3.05 m) harness and 3 blade connector. Installation  Fits Mercury/Mariner models equipped with integral trim pump.
             requires power trim "Y" harness (58366A 2).  Provides tilt control from the bow or
             transom location.
             Fits Mercury/Mariner models equipped with remote mounted trim pump.
















             2021 OEM Rigging & Accessories Guide & Price List                                              217
