ELECTRICAL

Cable AWG Length Part Number POSITIVE BATTERY CABLE
VSR to Battery Cable (Red) 2AWG 2 ft 84-8M0151962
2AWG 3 ft 84-8M0151963
2AWG 6 ft 84-8M0151964
Components

Component Specs Part Number
MBRF Fuse Holder 1/4 Output, 3/8 Input 88-8M0129529
MBRF Fuse Holder 5/16 Output, 3/8 Input 84-8M0144608
MBRF Fuse 30 amp 88-8M0129533
50 amp 88-8M0129534 84-8M0136941 80.55
80 amp 88-8M0129535 1 cable in the kit (red),12 feet long, 2 AWG, 5/16" ring terminal engine side and
100 amp 88-8M0130941 3/8" ring terminal battery side
When the application demands 2AWG wire size
125 amp 88-8M0129562
150 amp 88-8M0129528 NEGATIVE BATTERY CABLE
175 amp 88-8M0174088
200 amp 88-8M0129530
250 amp 88-8M0129531
Positive Hot Stud (Red) 5/16 Stud 85-875302A 1
Hot Stud Kit-Positive (Red) 5/16 Stud 8M0150037
Hot Stud Jumper Harness 18 in - 3/8 to 3/8 84-8M0150102 ELECTRICAL
Hot Stud Jumper Harness 12 in - 3/8 to 1/4 84-8M0150088
Isolator - Alt Engine Hot Stud Bolt 10- 40011145
Red Cable Boot 85-8M0084147
Battery Isolator Adapter Hot Stud Kit MCM 8M0162865
84-8M0136942 80.55
Charge Distribution Devices 1 cable in the kit (black),12 feet long, 2 AWG, 5/16" ring terminal engine side
and 3/8" ring terminal battery side
When the application demands 2AWG wire size
Component Specs Part Number
Isolator - Victron Argo Diode (dual) 80 amp 87-8M6005583 BATTERY CABLE KIT
Isolator - Victron Argo Diode (dual) 160 amp 8M0144607
Isolator - Victron Argo FET (dual) 200 amp (mosFet) 87-8M6005584
BATTERY CABLES

BATTERY CABLE KIT

84- 88439A50 62.55
Pair of 12 ft.(3.7 m) cables, 1 red (+) Positive and 1 black ( ‑) Negative, 4 gauge
with ring terminals. This is an optional accessory kit and may not reflect the original
cables on your engine. For original manufactured service part replacement, the
Electronic Parts Catalog should always be used for each specific engine. For
alternate length cables, consult the approriate service manual.
84-8M0133542 95.55 Fits Mercury/Mariner outboard engines.
2 cables in the kit (one red, one black),12 feet long, 2 AWG, 5/16" ring terminal
engine side and 3/8" ring terminal battery side HEAVY DUTY BATTERY CABLES
When the application demands 2 gauge wire size.

84- 61378A 2 25.98
For use with Mercury/Mariner V‑6 Outboards
