Page 237 - OEM RIGGING AND ACCESSORIES GUIDE (2021) - 8M0174477

ELECTRICAL

175HP+ KICKER ELECTRICAL KIT BATTERY CABLE - 6 INCH, 16 GA

8M0149838 116.66
This system allows you to run your kicker engine and use the power
steering system without your primary engine running. This system allows
you to connect to a deep cell battery (not your starter battery) and the 84-8M0094651 1.70
system will provide normal power steering from the wheel. The system will alert 6 inch red battery cable (component of isolator kit 8M0094239), 16 gauge
you when your auxiliary battery is below 9.5 volts. This signal means that you must Can be used as part of a battery isolator kit , signal sense lead or short jumper
start your primary engine to change the battery system. This kit will save the
starting battery for primary starting use only. Must select the appropriate isolator CABLE/FUSE ASY - 100 AMP -BATTERY ISOLATOR
and isolator cables to be paired with this system, dependent on engine
configuration.
175hp+ power steering systems with a kicker engine. 200‑350 Verado 2015 (Gen
5) and newer and all 175‑300hp 3.4L and 4.6L engines.
ELECTRICAL ISOLATOR KIT- DUAL OPTI AND 150
FOURSTROKE

ELECTRICAL 8M0134605 192.68

WARNING: Cancer - www.P65Warnings.ca.gov
Used to add Power steering option to Dual OptiMax or 150 FourStroke engines 84-898180K01 59.78
Dual OptiMax or 150 FourStroke Engines Improved heat handling capacity cable used with battery isolators and
Verado kits
ELECTRICAL ISOLATOR KIT- TRIPLE OPTI AND 150
FOURSTROKE
BATTERY SWITCH
BATTERY SELECTOR SWITCH
8M0134606
Used to add Power steering option to Triple OptiMax or 150 FourStroke engines
Triple OptiMax and 150 FourStroke Engines
BATTERY ISOLATOR HARNESS KIT

67-829721 41.09
Ignition protected. Standard features include a make before break design, for use
with two or more batteries, single or dual engine systems (for dual engine systems,
two switches are required). They permit selection between batteries for starting
and charging or operation of both batteries in parallel. They allow the addition of
84-8M0094239 58.50 an extra battery for use with accessories. The OFF position also acts as an
emergency disconnect in the event of an electrical problem. Surface mount, red
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov [plastic housing with large black plastic knob. Incorporates an improved design to
Allows the connection of any battery isolator to Mercury/Mariner outboard. Kit protect the copper contacts and brass terminals used as electrical connections.
includes a 10 gauge red cable (8 ft.[2.44 m] length) that connects from the For use with systems under 50 volts. Capacity: 250 amps continuous, 360 amps
regulator output terminal to the battery isolator input terminal. intermittent. 5‑1/4 in. (133 mm) diameter, 2‑5/8 in. (67 mm) depth.
Fits Mercury/Mariner 50‑125 hp. (2000 & prior) with high output (16 amp.) 67-829722 49.47
alternator and V‑6 models (1999 & prior) equipped with 40 amp. alternator or dual With Alternator Field Disconnect. Ignition protected. Standard features include a
20‑amp alternator systems and fits the F75‑115 hp. (2.1L) FourStroke and the make before break design, for use with two or more batteries, single or dual engine
F150 EFI FourStroke outboard. Connections from battery isolator to the batteries systems (for dual engine systems, two switches are required). They permit
are not included. selection between batteries for starting and charging or operation of both batteries
in parallel. They allow the addition of an extra battery for use with accessories.
The "OFF" position also acts as an emergency disconnect in the event of an
electrical problem. In addition to the standard features listed above, the advantage
these models feature is that they will prevent damage to the alternator* if
accidentally switched to the "OFF" position while the engine is running.
