STEERING

JET DRIVE STEERING CABLE ROD END BULKHEAD BELLOWS KIT

STEERING ROD END

850697A 2 21.09
Fits Jet Drive models with 40 series cables
883053A 1 41.14 FITTING - BULKHEAD 3/4 IN. MALE TO MALE
For 135 & 540 deg. steering systems. 5/16 in. (7.9 mm)
Fits Sport Jet models with 60 series cables
STEERING CABLE BULKHEAD FITTINGS AND
BELLOWS KITS

Hardware used to complete Sport Jet installations. Use either bulkhead
fittings or bellows kit. Not for use together.
BULKHEAD COMPRESSION FITTINGS
22-892517 12.63
Fitting ‑ Bulkhead 3/4 in. Male To Male.
Used to install a bulkhead installation 0 in. to 3/4 in Maximum wall thickness grip
length‑ Power Steering.
FITTING- BULKHEAD 3 IN. MALE TO MALE

820675 4.39
Fits Sport‑Jet 90/95/120 and 175 with 40 series cables. Also fits 200 OptiMax, 210
& 240 EFI Jet Drives.
BULKHEAD BELLOWS KIT

22-892518
STEERING Fitting‑ Bulkhead 3 in. ‑ Male To Male 13.13
Power Steering Fittings.
Used to install bulkhead installations 3/4 in. to 3 in. maximum wall thickness grip
length.
STRAIGHT FITTING 9/16 IN.

850005A 2 22.22
For 135 & 270 deg. steering systems and 60 series cables.
Fits Jet Drive models with 60 series cables

22-892519 9.65

Fitting‑ Straight 9/16 in. to Cylinder ‑ 6 to 4.
Power Steering fittings.
Allows straight cylinder hose connections at Outboard Steering cylinder vs 90
degree (replaces 889552)
