Page 656 - OEM RIGGING AND ACCESSORIES GUIDE (2021) - 8M0174477
P. 656
MISCELLANEOUS PARTS
MISCELLANEOUS PARTS
SCREWS SCREW
SCREW
10- 53167T .50
5/16‑18 x 7/8 in., Hex head
For mounting shift cable retainer to Bravo shift bracket.
10- 24231 .40
#10‑24 x 1/4 in., Slotted binding head Priced individually, sold @ multiples of 16
For mounting Bravo grounding straps SCREW
Priced individually, sold @ multiples of 5
SCREW MISCELLANEOUS PARTS
10-8M0113180 1.95
3/8‑16 x 1 in., 12 point flange head
For mounting MCM thermostat housing, exhaust block‑off plate and Alpha/Bravo
10- 48409 .90 top cover.
#10‑16 x 5/8 in., Stainless steel self‑tapping pan head
For mounting MCM P/T pump solenoid boot SCREW
Priced individually, sold @ multiples of 2
SCREW
10-8M0113174 2.87
3/8‑16 x 1‑1/4 in., 12 point flange head
For mounting MCM lower exhaust pipe to outer transom plate.
10- 78038 1.25 Priced individually, sold @ multiples of 5
1/4‑20 x 1‑3/4 in., Hex head
For mounting Bravo inlet water hose connector SCREW
Priced individually, sold @ multiples of 3
10- 43749 3.45
.375‑16 x 5‑3/4 in., Hex flange head
For mounting MCM exhaust elbows
2021 OEM Rigging & Accessories Guide & Price List 643
