Page 657 - OEM RIGGING AND ACCESSORIES GUIDE (2021) - 8M0174477
P. 657
MISCELLANEOUS PARTS
SCREW SCREW
10-864665 4.25 10-821300 40 3.10
3/8‑16 x 7‑1/2 in., Hex head M6 x 40, Stainless steel hex flange head w/ lock patch
For mounting MIE dry joint exhaust elbows. For mounting O/B lower cowling
SCREW SCREW
MISCELLANEOUS PARTS 10-805159 1.95 10-863322 1 5.55
7/16‑20 x 1‑1/2 in., Hex head
For mounting MCM 496 Mag & MIE 8.1S MPI top engine cover.
For transmission & driveshaft mounting flange
REAR ENGINE MOUNT BOLT KIT M6 x 65, Black internal 6 lobe pan head
STUDS
STUD
10- 97934A 1 9.95
Fits R, MR, Alpha One, Gen II & Bravo drives
REAR ENGINE MOUNT BOLT 16- 55422 2.60
#10‑32 x 2 in., Cadmium plated steel
Priced individually, sold @ multiples of 5
STUD
16-861316 5.95
3/8‑16 x 2‑3/4 in., Hex shoulder
For MCM/MIE flywheel housing grounding stud
10- 97934 2.40
1/2‑20 x 5‑1/4 in., Hex head
