Page 1024 - Quicksilver Product Guide (2020) - 8M0163242

DRIVE SYSTEMS

Model Gear Ratio Year Range Serial # Range Sterndrive Unit - Upper Drive Shaft Upper Drive Shaft Lower Gear Housing - Lower Gear Housing
Complete Housing - Complete Housing - Basic Complete - Basic
Alpha One Gen II (CR) 1.65/1.62 1991 - 1995 0D469859 - 0F679999 5-5111300TP 1547-861063A10 N.L.A. 1623-815822A47 1623-815822A28
Alpha One Gen II (CR) 1.65/1.62 1996 - 1997 0F680000 - 0K999999 5-5111300TP 1547-861063A10 N.L.A. 1623-815822A47 1623-815822A36
Alpha One Gen II (CR) 1.65/1.62 1998 - 2019 0L100040 and up 5-5111300TP 1547-861063A10 1547-861063A 4 1623-815822A47 1623-815822A36
Alpha One Gen II (CR) 1.84/1.81 1991 - 1995 0D469859 - 0F679999 5-5111400TP 1547-861063A 8 N.L.A. 1623-815822A47 1623-815822A28
Alpha One Gen II (CR) 1.84/1.81 1996 - 1997 0F680000 - 0K999999 5-5111400TP 1547-861063A 8 N.L.A. 1623-815822A47 1623-815822A36
Alpha One Gen II (CR) 1.84/1.81 1998 - 2019 0L100040 and up 5-5111400TP 1547-861063A 8 1547-861063A 4 1623-815822A47 1623-815822A36
Alpha One Gen II (CR) 1.98/1.94 1991 - 1995 0D469859 - 0F679999 5-5111600TP 1547-861063A 6 N.L.A. 1623-815822A47 1623-815822A28
Alpha One Gen II (CR) 1.98/1.94 1996 - 1997 0F680000 - 0K999999 5-5111600TP 1547-861063A 6 N.L.A. 1623-815822A47 1623-815822A36
Alpha One Gen II (CR) 1.98/1.94 1998 - 2019 0L100040 and up 5-5111600TP 1547-861063A 6 1547-861063A 4 1623-815822A47 1623-815822A36
Alpha One Gen II (CR) 2.00 1996 - 1997 0F680000 - 0K999999 5-5111600TP 1547-861063A10 N.L.A. 1623-815822A52 1623-815822A36
Alpha One Gen II (CR) 2.00 1998 - 2019 0L100040 and up 5-5111600TP 1547-861063A10 1547-861063A 4 1623-815822A52 1623-815822A36
Vazer 2.58 2007 - 2009 0W995500 and up N.L.A. N.L.A. N.L.A. N.L.A. N.L.A.
Vazer 2.77 2007 - 2009 0W995500 and up N.L.A. N.L.A. N.L.A. N.L.A. N.L.A.
Bravo I 1.36 1988 - 1990 0B664190 - 0D469908 N.L.A.(4) N.L.A. 1589- 8868A15 N.L.A. 1656- 8866A11
Bravo I 1.36 1991 - 1999 0D469909 - 0M100000 N.L.A.(4) 1589-863836A50 1589- 8868G21 1656- 8866A63(4) 1656- 8866A64(4)
Bravo I 1.36 2000 - 2004 0M100001 - 0W249999 N.L.A.(4) 1589-863836A50 1589-864571A72 1656- 8866A63(4) 1656- 8866A64(4)
Bravo I 1.36 2004 - 2019 0W250000 and up 5-5231100TP 1589-865440H50 1589-865440H72 1656- 8866A63 1656- 8866A64
Bravo I 1.50 1988 - 1990 0B664190 - 0D469908 5-5231200NP(4) N.L.A. 1589- 8868A15 N.L.A. 1656- 8866A11
Bravo I 1.50 1991 - 1999 0D469909 - 0M100000 5-5231200NP(4) 1589-863836A51 1589- 8868G21 1656- 8866A63(4) 1656- 8866A64(4) MERCURY® MERCRUISER®
Bravo I 1.50 2000 - 2004 0M100001 - 0W249999 5-5231200NP(4) 1589-863836A51 1589-864571A72 1656- 8866A63(4) 1656- 8866A64(4)
Bravo I 1.50 2004 - 2019 0W250000 and up 5-5231200TP 1589-865440H51 1589-865440H72 1656- 8866A63 1656- 8866A64
Bravo I 1.65 1991 - 1999 0D469909 - 0M100000 N.L.A.(4) 1589-863836A52 1589- 8868G21 1656- 8866A63(4) 1656- 8866A64(4)
Bravo I 1.65 2000 - 2004 0M100001 - 0W249999 N.L.A.(4) 1589-863836A52 1589-864571A72 1656- 8866A63(4) 1656- 8866A64(4)
Bravo I 1.65 2004 - 2019 0W250000 and up 5-5231300TP 1589-865440H52 1589-865440H72 1656- 8866A63 1656- 8866A64
Bravo I-Diesel 1.36 1991 - 1999 0D469909 - 0M100000 N.L.A.(6) 1589-863836A66 1589- 8868G21 1656- 8866A63(4) 1656- 8866A64(4)
Bravo I-Diesel 1.50 1991 - 1999 0D469909 - 0M100000 N.L.A.(6) 1589-863836A67 1589- 8868G21 1656- 8866A63(4) 1656- 8866A64(4)
Bravo I-Diesel 1.65 1991 - 1999 0D469909 - 0M100000 N.L.A.(6) N.L.A. 1589- 8868G21 1656- 8866A63(4) 1656- 8866A64(4)
Bravo I-Performance 1.36 1991 - 1999 0D469909 - 0M100000 N.L.A.(3)(7) 1589-863836A50 1589- 8868G21 N.L.A.(3) 1656- 8866A54(3)
Bravo I-Performance 1.50 1991 - 1999 0D469909 - 0M100000 N.L.A.(3)(7) 1589-863836A51 1589- 8868G21 N.L.A.(3) 1656- 8866A54(3)
Bravo I-Performance 1.65 1991 - 1999 0D469909 - 0M100000 N.L.A.(3)(7) 1589-863836A52 1589- 8868G21 N.L.A.(3) 1656- 8866A54(3)
Bravo I-SeaCore 1.36 2007 - 2019 0W995000 and up N.L.A. 1500-866458J01 1500-866458J00 1656- 8866J01 1656- 8866J00
Bravo I-Seacore 1.50 2007 - 2019 0W995000 and up 5-5J31200TP 1500-866458J02 1500-866458J00 1656- 8866J01 1656- 8866J00
Bravo I-SeaCore 1.65 2007 - 2019 0W995000 and up 5-5J31300TP 1500-866458J03 1500-866458J00 1656- 8866J01 1656- 8866J00
Bravo I X 1.36 2000 - 2004 0M100001 - 0W249999 N.L.A.(4)(7) 1589-863836A66 1589-864571A70 1656- 8866A63(4) 1656- 8866A64(4)
Bravo I X 1.36 2004 - 2019 0W250000 and up 5-5237100TP 1589-865440H66 1589-865440H70 1656- 8866A63 1656- 8866A64
Bravo I X 1.50 2000 - 2004 0M100001 - 0W249999 N.L.A.(4)(7) 1589-863836A67 1589-864571A70 1656- 8866A63(4) 1656- 8866A64(4)
Bravo I X 1.50 2004 - 2019 0W250000 and up 5-5237200TP 1589-865440H67 1589-865440H70 1656- 8866A63 1656- 8866A64
Bravo I X 1.65 2000 - 2004 0M100001 - 0W249999 N.L.A.(4)(7) N.L.A. 1589-864571A70 1656- 8866A63(4) 1656- 8866A64(4)
Bravo I X 1.65 2004 - 2019 0W250000 and up 5-5237300TP 1589-865440H68 1589-865440H70 1656- 8866A63 1656- 8866A64
Bravo I X-SeaCore 1.36 2007 - 2019 0W995000 and up N.L.A. 1500-866459J01 1500-866459J00 1656- 8866J01 1656- 8866J00
Bravo I X-Seacore 1.50 2007 - 2019 0W995000 and up 5-5J37200TP 1500-866459J02 1500-866459J00 1656- 8866J01 1656- 8866J00
Bravo I X-SeaCore 1.65 2007 - 2019 0W995000 and up 5-5J37300TP 1500-866459J03 1500-866459J00 1656- 8866J01 1656- 8866J00
Bravo I XR 1.26 2000 - 2004 0M100001 - 0W239999 N.L.A.(3)(7) 1589-863836A56 1589-864571A70 1656- 8866A80(3) 1656- 8866A54(3)
Bravo I XR 1.26 2004 - 2019 0W240000 and up (3) 1589-865440H56 1589-865440H70 1656- 8866A80(3) 1656- 8866A54(3)
Bravo I XR 1.26 2000 - 2004 0M100001 - 0W239999 N.L.A.(4)(7) 1589-863836A56 1589-864571A70 N.L.A.(4) 1656- 8866A64(4)
Bravo I XR 1.26 2004 - 2019 0W240000 and up N.L.A.(4) 1589-865440H56 1589-865440H70 N.L.A.(4) 1656- 8866A64(4)
Bravo I XR 1.35 2000 - 2004 0M100001 - 0W239999 N.L.A.(3)(7) 1589-863836A56 1589-864571A70 N.L.A.(3) 1656- 8866A54(3)
Bravo I XR 1.35 2004 - 2019 0W240000 and up (3) 1589-865440H56 1589-865440H70 N.L.A.(3) 1656- 8866A54(3)
Bravo I XR 1.35 2000 - 2004 0M100001 - 0W239999 N.L.A.(4)(7) 1589-863836A56 1589-864571A70 1656- 8866A83(4) 1656- 8866A64(4)
Bravo I XR 1.35 2004 - 2019 0W240000 and up 5-5E31900UP(4) 1589-865440H56 1589-865440H70 1656- 8866A83(4) 1656- 8866A64(4)
Bravo I XR 1.50 2000 - 2004 0M100001 - 0W239999 N.L.A.(3) 1589-863836A56 1589-864571A70 1656- 8866A61(3) 1656- 8866A54(3)
Bravo I XR 1.50 2004 - 2019 0W240000 and up (3) 1589-865440H56 1589-865440H70 1656- 8866A61(3) 1656- 8866A54(3)
Bravo I XR 1.50 2000 - 2004 0M100001 - 0W239999 N.L.A.(4)(7) 1589-863836A56 1589-864571A70 1656- 8866A62(4) 1656- 8866A64(4)
Bravo I XR 1.50 2004 - 2019 0W240000 and up 5-5E31200UP(4) 1589-865440H56 1589-865440H70 1656- 8866A62(4) 1656- 8866A64(4)
