Page 1026 - Quicksilver Product Guide (2020) - 8M0163242

DRIVE SYSTEMS

Model Gear Ratio Year Range Serial # Range Sterndrive Unit - Upper Drive Shaft Upper Drive Shaft Lower Gear Housing - Lower Gear Housing
Complete Housing - Complete Housing - Basic Complete - Basic
Bravo II X-SeaCore 1.65 2007 - 2019 0W995000 and up 5-5K32300TP 1500-866459J02 1500-866459J00 1641- 8294J02 1641- 8294J00
Bravo II X-SeaCore 1.81 2007 - 2019 0W995000 and up 5-5K37400TP 1500-866459J01 1500-866459J00 1641- 8294J01 1641- 8294J00
Bravo II X-SeaCore 2.00 2007 - 2019 0W995000 and up 5-5K37600TP 1500-866459J02 1500-866459J00 1641- 8294J01 1641- 8294J00
Bravo II X-SeaCore 2.20 2007 - 2019 0W995000 and up 5-5K32500TP 1500-866459J03 1500-866459J00 1641- 8294J01 1641- 8294J00
Bravo III 1.36 1993 - 1999 0D784124 - 0M100000 N.L.A.(7) 1589-863836A50 1589- 8868G21 1656-8M0046733 1656- 8866G01
Bravo III 1.36 2000 - 2004 0M100001 - 0W249999 N.L.A.(7) 1589-863836A50 1589-864571A72 1656-8M0046733 1656- 8866G01
Bravo III 1.36 2004 - 2019 0W250000 and up N.L.A. 1589-865440H50 1589-865440H72 1656-8M0046733 1656- 8866G01
Bravo III 1.50 1993 - 1999 0D784124 - 0M100000 N.L.A.(7) 1589-863836A51 1589- 8868G21 1656-8M0046733 1656- 8866G01
Bravo III 1.50 2000 - 2004 0M100001 - 0W249999 N.L.A.(7) 1589-863836A51 1589-864571A72 1656-8M0046733 1656- 8866G01
Bravo III 1.50 2004 - 2019 0W250000 and up 5-5441200TP 1589-865440H02 1589-865440H72 1656-8M0046733 1656- 8866G01
Bravo III 1.65 1993 - 1999 0D784124 - 0M100000 N.L.A. 1589-863836A51 1589- 8868G21 1656-8M0046735 1656- 8866G01
Bravo III 1.65 2000 - 2004 0M100001 - 0W249999 N.L.A. 1589-863836A51 1589-864571A72 1656-8M0046735 1656- 8866G01
Bravo III 1.65 2004 - 2019 0W250000 and up 5-5441300TP 1589-865440H51 1589-865440H72 1656-8M0046735 1656- 8866G01
Bravo III 1.81 1993 - 1999 0D784124 - 0M100000 5-5441400LP 1589-863836A50 1589- 8868G21 1656- 8866G09 1656- 8866G01
Bravo III 1.81 2000 - 2004 0M100001 - 0W249999 5-5441400LP 1589-863836A50 1589-864571A72 1656- 8866G09 1656- 8866G01
Bravo III 1.81 2004 - 2019 0W250000 and up 5-5441400TP 1589-865440H01 1589-865440H72 1656- 8866G09 1656- 8866G01
Bravo III 2.00 1993 - 1999 0D784124 - 0M100000 5-5441600LP 1589-863836A51 1589- 8868G21 1656- 8866G09 1656- 8866G01
Bravo III 2.00 2000 - 2004 0M100001 - 0W249999 5-5441600LP 1589-863836A51 1589-864571A72 1656- 8866G09 1656- 8866G01
Bravo III 2.00 2004 - 2019 0W250000 and up 5-5441600TP 1589-865440H51 1589-865440H72 1656- 8866G09 1656- 8866G01 MERCURY® MERCRUISER®
Bravo III 2.20 1993 - 1999 0D784124 - 0M100000 5-5441500LP 1589-863836A52 1589- 8868G21 1656- 8866G09 1656- 8866G01
Bravo III 2.20 2000 - 2004 0M100001 - 0W249999 5-5441500LP 1589-863836A52 1589-864571A72 1656- 8866G09 1656- 8866G01
Bravo III 2.20 2000 - 2004 0W250000 and up 5-5441500TP 1589-865440H52 1589-865440H72 1656- 8866G09 1656- 8866G01
Bravo III 2.43 1993 - 1999 0D784124 - 0M100000 N.L.A.(7) 1589-863836A52 1589- 8868G21 1656-8M0046682 1656- 8866G01
Bravo III 2.43 2000 - 2004 0M100001 - 0W249999 N.L.A.(7) 1589-863836A52 1589-864571A72 1656-8M0046682 1656- 8866G01
Bravo III 2.43 2004 - 2019 0W2500000 and up 5-5441700TP 1589-865440H52 1589-865440H72 1656-8M0046682 1656- 8866G01
Bravo III-Diesel 1.36 1993 - 1999 0D784124 - 0M100000 N.L.A.(6) 1589-863836A66 1589- 8868G21 1656-8M0046733 1656- 8866G01
Bravo III-Diesel 1.50 1993 - 1999 0D784124 - 0M100000 N.L.A.(6) 1589-863836A67 1589- 8868G21 1656-8M0046733 1656- 8866G01
Bravo III-Diesel 1.65 1993 - 1999 0D784124 - 0M100000 N.L.A.(6) 1589-863836A67 1589- 8868G21 1656-8M0046735 1656- 8866G01
Bravo III-Diesel 1.81 1993 - 1999 0D784124 - 0M100000 N.L.A.(6) 1589-863836A66 1589- 8868G21 1656- 8866G09 1656- 8866G01
Bravo III-Diesel 2.00 1993 - 1999 0D784124 - 0M100000 N.L.A.(6) 1589-863836A67 1589- 8868G21 1656- 8866G09 1656- 8866G01
Bravo III-Diesel 2.20 1993 - 1999 0D784124 - 0M100000 N.L.A.(6) N.L.A. 1589- 8868G21 1656- 8866G09 1656- 8866G01
Bravo III-Diesel 2.43 1993 - 1999 0D784124 - 0M100000 N.L.A.(6) N.L.A. 1589- 8868G21 1656-8M0046682 1656- 8866G01
Bravo III-SeaCore 1.65 2007 - 2019 0W995000 and up 5-5L41300TP 1500-866458J02 1500-866458J00 1656- 8866J24 1656- 8866J30
Bravo III-SeaCore 1.81 2007 - 2019 0W995000 and up 5-5L41400TP 1500-866458J04 1500-866458J00 1656- 8866J09 1656- 8866J30
Bravo III-SeaCore 2.00 2007 - 2019 0W995000 and up 5-5L41600TP 1500-866458J02 1500-866458J00 1656- 8866J09 1656- 8866J30
Bravo III-SeaCore 2.20 2007 - 2019 0W995000 and up 5-5L41500TP 1500-866458J03 1500-866458J00 1656- 8866J09 1656- 8866J30
Bravo III-SeaCore 2.43 2007 - 2019 0W995000 and up 5-5L41700TP 1500-866458J03 1500-866458J00 1656- 8866J25 1656- 8866J30
Bravo III X 1.36 2000 - 2004 0M100001 - 0W249999 5-5442100TZ(7) 1589-863836A66 1589-864571A70 1656-8M0046733 1656- 8866G01
Bravo III X 1.36 2004 - 2010 0W250000 - 0W987799 5-5442100TZ(8) 1589-865440H66 1589-865440H70 1656-8M0046733 1656- 8866G01
Bravo III X 1.36 2010 - 2019 0W987800 and up 5-5442100TZ(4) 1589-865440H66 1589-865440H70 1656-8M0046733(4) 1656-8M0046683(4)
Bravo III X 1.50 2000 - 2004 0M100001 - 0W249999 5-5442200TZ 1589-863836A67 1589-864571A70 1656-8M0046733 1656- 8866G01
Bravo III X 1.50 2004 - 2010 0W250000 - 0W987799 5-5442200TZ(8) 1589-865440H67 1589-865440H70 1656-8M0046733(8) 1656- 8866G01(8)
Bravo III X 1.50 2010 - 2019 0W987800 and up 5-5442200TZ(4) 1589-865440H67 1589-865440H70 1656-8M0046733(4) 1656-8M0046683(4)
Bravo III X 1.65 2000 - 2004 0M100001 - 0W249999 5-5442300TZ 1589-863836A67 1589-864571A70 1656-8M0046735 1656- 8866G01
Bravo III X 1.65 2004 - 2010 0W250000 - 0W987799 5-5442300TZ(8) 1589-865440H67 1589-865440H70 1656-8M0046735(8) 1656- 8866G01(8)
Bravo III X 1.65 2010 - 2019 0W987800 and up 5-5442300TZ(4) 1589-865440H67 1589-865440H70 1656-8M0046735(4) 1656-8M0046683(4)
Bravo III X 1.81 2000 - 2004 0M100001 - 0W249999 N.L.A.(7) 1589-863836A66 1589-864571A70 1656- 8866G09 1656- 8866G01
Bravo III X 1.81 2004 - 2010 0W250000 - 0W987799 5-5447400TZ(8) 1589-865440H66 1589-865440H70 1656- 8866G09(8) 1656- 8866G01(8)
Bravo III X 1.81 2010 - 2019 0W987800 and up 5-5447400TZ(4) 1589-865440H66 1589-865440H70 1656-8M0046738(4) 1656-8M0046683(4)
Bravo III X 2.00 2000 - 2004 0M100001 - 0W249999 N.L.A.(7) 1589-863836A67 1589-864571A70 1656- 8866G09 1656- 8866G01
Bravo III X 2.00 2004 - 2010 0W250000 - 0W987799 5-5447600TZ(8) 1589-865440H67 1589-865440H70 1656- 8866G09(8) 1656- 8866G01(8)
Bravo III X 2.00 2010 - 2019 0W987800 and up 5-5447600TZ(4) 1589-865440H67 1589-865440H70 1656-8M0046738(4) 1656-8M0046683(4)
Bravo III X 2.20 2000 - 2004 0M100001 - 0W249999 N.L.A.(7) N.L.A. 1589-864571A70 1656- 8866G09 1656- 8866G01
Bravo III X 2.20 2004 - 2010 0W250000 - 0W987799 5-5447500TZ(8) 1589-865440H68 1589-865440H70 1656- 8866G09(8) 1656- 8866G01(8)

Quicksilver Product Guide 1017
