Page 626 - Quicksilver Product Guide (2020) - 8M0163242

GEAR CASE COMPONENTS

DRAIN SCREW GASKET MERCURY®/MARINER®/FORCE®

26-830749
A rubber coated, stainless steel washer forms a tear resistant gearcase drain
screw seal.
Used with the 3/8‑16 drain/fill screw found on all MerCruiser and most Mercury/
Mariner outboard gearcases except those of Japanese origin..
GEARCASE FILL SCREW

10-880717A01
Gearlube fill screw and sealing washer that is located in the bearing carrier.
Fits the standard gearcase on the 135‑300 hp. Verado outboard and the 3.0L
Optimax. Use only if screw location is in the bearing carrier.
FILL AND DRAIN SCREW KIT

22-8M0083059
Includes the screw and the tear resistant rubber coated seal.
Fits Mercury/Mariner outboards of Japanese origin that use an 8x1.25 metric
threaded screw.
Quicksilver Branded, Clamshell Package Point of Sale Packaged.

Quicksilver Product Guide 617
