P. 696
IGNITION
Model CID/ #Cyl Type of Ignition Year Range Serial # Range ECM/ ICM Ignition Coil Wire Kit Spark Plug Gap
4.5L MPI 250 Alpha (DTM) 275/ V-6 Mercury 2014 - 2016 2A441953 - 2A530777 78-8M0128050 300-8M0044991 84-8M0095475 33-8M0095454 .050
4.5L MPI 250 Alpha (DTM) 275/ V-6 Mercury 2016 - 2019 2A530778 and up 77-8M0124457 300-8M0044991 84-8M0095475 33-8M0095454 .050
4.5L MPI 250 Alpha EC (DTM) 275/ V-6 Mercury 2014 - 2016 2A441953 - 2A530777 78-8M0128049 300-8M0044991 84-8M0095475 33-8M0095454 .050
4.5L MPI 250 Alpha EC (DTM) 275/ V-6 Mercury 2016 - 2019 2A530778 and up 77-8M0124456 300-8M0044991 84-8M0095475 33-8M0095454 .050
4.5L MPI 250 Bravo (DTS) 275/ V-6 Mercury 2014 - 2016 2A441953 - 2A530777 78-8M0128051 300-8M0044991 84-8M0095475 33-8M0095454 .050
4.5L MPI 250 Bravo (DTS) 275/ V-6 Mercury 2016 - 2019 2A530778 and up 77-8M0124458 300-8M0044991 84-8M0095475 33-8M0095454 .050
4.5L MPI 250 Bravo (DTM) 275/ V-6 Mercury 2014 - 2016 2A441953 - 2A530777 78-8M0128056 300-8M0044991 84-8M0095475 33-8M0095454 .050
4.5L MPI 250 Bravo (DTM) 275/ V-6 Mercury 2016 - 2019 2A530778 and up 77-8M0124461 300-8M0044991 84-8M0095475 33-8M0095454 .050
4.5L MPI 250 Bravo EC (DTS) 275/ V-6 Mercury 2014 - 2016 2A441953 - 2A530777 78-8M0128052 300-8M0044991 84-8M0095475 33-8M0095454 .050
4.5L MPI 250 Bravo EC (DTS) 275/ V-6 Mercury 2016 - 2019 2A530778 and up 77-8M0124459 300-8M0044991 84-8M0095475 33-8M0095454 .050
4.5L MPI 250 Bravo EC (DTM) 275/ V-6 Mercury 2014 - 2016 2A441953 - 2A530777 78-8M0128053 300-8M0044991 84-8M0095475 33-8M0095454 .050
4.5L MPI 250 Bravo EC (DTM) 275/ V-6 Mercury 2016 - 2019 2A530778 and up 77-8M0124460 300-8M0044991 84-8M0095475 .050
215 MCM & MIE (Ford) 302/ V-8 Autolite 1970 - 1972 2781153 - 3563181 N/A 898253T24 84-816761Q 9 N.L.A. .030
215 MCM & MIE (Ford) 302/ V-8 Mallory 1970 - 1972 2781153 - 3563181 N/A 898253T24 84-816761Q 9 33-813425 .030
225 MCM & MIE (Ford) 302/ V-8 Autolite 1973 - 1974 3385721 - 4166999 N/A 898253T24 84-816761Q 9 33-813425 .030
225 MCM & MIE (Ford) 302/ V-8 Mallory 1973 - 1974 3385721 - 4166999 N/A 898253T24 84-816761Q 9 33-813425 .030
225 MCM & MIE (Ford) 302/ V-8 Mercury 1973 - 1974 3385721 - 4166999 N/A 898253T24 84-816761Q 9 33-813425 .030
888 (Ford) 302/ V-8 Mercury 1971 - 1977 3108723 - 4887829 N/A 898253T24 84-816761Q 9 33-813425 .030
888 (Ford) 302/ V-8 Prestolite 1971 - 1977 3108723 - 4887829 N/A 898253T24 84-816761Q 9 33-813425 .030 MERCURY® MERCRUISER®
888 (Ford) 302/ V-8 Mallory 1971 - 1977 3108723 - 4887829 N/A 898253T24 84-816761Q 9 33-813425 .030
888 (Ford) 302/ V-8 Autolite 1971 - 1977 3108723 - 4887829 N/A 898253T24 84-816761Q 9 33-813425 .030
190 (GM 283) 283/ V-8 Delco 1963 - 1964 1564539 - 1730903 N/A 300-8M0079202 84-816761Q 9 N.L.A. .035
198 MIE 305/ V-8 Mallory 1977 4776402 - 4931099 N/A 898253T24 84-816761Q 9 33-898264001 .035
200 305/ V-8 Thunderbolt IV 1985 - 1987 6899058 - 0B525981 15248T01 300-8M0079202 84-816761Q 4 33-898264001 .035
200 305/ V-8 Thunderbolt IV(2) 1987 0B525982 - 0B774444 15899T02 300-8M0079202 84-816761Q 4 33-898264001 .035
200 305/ V-8 Thunderbolt IV(1) 1987 0B525982 - 0B774444 15899T02 300-8M0079202 84-816761Q17 33-898264001 .035
228 305/ V-8 Mallory 1977 - 1982 4765100 - 6218461 N/A 898253T24 84-816761Q 9 33-898264001 .035
228 305/ V-8 Thunderbolt IV 1983 - 1984 6218462 - 6899268 15248T01 300-8M0079202 84-816761Q 4 33-898264001 .035
228 MIE 305/ V-8 Mallory 1977 - 1980 4765100 - 5907057 N/A 898253T24 84-816761Q 9 33-898264001 .035
230 305/ V-8 Thunderbolt IV 1985 - 1987 6899269 - 0B525981 15248T01 300-8M0079202 84-816761Q 4 33-898264001 .035
230 305/ V-8 Thunderbolt IV(2) 1987 0B525982 - 0B773739 15899T02 300-8M0079202 84-816761Q 4 33-898264001 .035
230 305/ V-8 Thunderbolt IV(1) 1987 0B525982 - 0B773739 15899T02 300-8M0079202 84-816761Q17 33-898264001 .035
230 MIE (LH) 305/ V-8 Thunderbolt IV 1981 - 1987 5907058 - 0B522505 15248T01 300-8M0079202 84-816761Q 4 33-898264001 .035
230 MIE (RH) 305/ V-8 Thunderbolt IV 1981 - 1987 5907058 - 0B522505 15248T01 300-8M0079202 84-816761Q 3 33-898264001 .035
230 MIE (LH) 305/ V-8 Thunderbolt IV 1987 0B522506 - 0B788151 15899T02 300-8M0079202 84-816761Q 4 33-898264001 .035
230 MIE (RH) 305/ V-8 Thunderbolt IV 1987 0B522506 - 0B788151 15899T02 300-8M0079202 84-816761Q 3 33-898264001 .035
5.0L 305/ V-8 Thunderbolt IV(2) 1988 - 1992 0B774445 - 0F600999 15899T02 300-8M0079202 84-816761Q 4 33-898264001 .035
5.0L 305/ V-8 Thunderbolt IV(1) 1993 - 1995 0B774445 - 0F600999 15899T02 300-8M0079202 84-816761Q17 33-898264001 .035
5.0L Alpha (Gen +) 305/ V-8 Thunderbolt V 1998 - 2004 0L015751 - 0W300009 861459T02 300-8M0079202 84-816761Q17 33-816336Q .045
5.0L Alpha (Gen +) 305/ V-8 Thunderbolt V 2004 - 2009 0W300010 - 1A607561 861459T02 300-8M0079202 84-863656A05 33-816336Q .045
5.0L Bravo (Gen +) 305/ V-8 Thunderbolt V 1998 - 2004 0L015751 - 0W300009 861460T02 300-8M0079202 84-816761Q17 33-816336Q .045
5.0L Bravo (Gen +) 305/ V-8 Thunderbolt V 2004 - 2009 0W300010 - 1A607561 861460T02 300-8M0079202 84-863656A05 33-816336Q .045
5.0L EFI (Gen +) 305/ V-8 Delco - HEI 1998 0L012052 - 0L331630 861478T 1 806673T 1 84-816608Q70 33-816336Q .045
5.0L EFI (Gen +) 305/ V-8 Delco - HEI 1998 0L331651 - 0L339999 861478T 1 806673T 1 84-816608Q70 33-816336Q .045
5.0L EFI (Gen +) 305/ V-8 Mercury -HEI 1999 0L331631 - 0L331650 N.L.A. 300-8M0079202 84-816608Q83 33-816336Q .045
5.0L EFI (Gen +) 305/ V-8 Mercury -HEI 1999 - 2001 0L340000 - 0M299999 N.L.A. 300-8M0079202 84-816608Q83 33-816336Q .045
5.0L MIE (LH) 305/ V-8 Thunderbolt IV 1988 0B788152 - 0C396832 15899T02 300-8M0079202 84-816761Q 4 33-898264001 .035
5.0L MIE (RH) 305/ V-8 Thunderbolt IV 1988 0B788152 - 0C396832 15899T02 300-8M0079202 84-816761Q 3 33-898264001 .035
5.0L MPI Alpha 305/ V-8 Delco - HEI 2001 - 2002 0M300000 - 0M599999 865834T03 8M0054588 84-863656A 1 33-8M2018369 .060
5.0L MPI Alpha, RWC 305/ V-8 Delco - HEI 2002 - 2004 0M600000 - 0W309999 865834T03(10) 8M0054588 84-863656A 1 33-8M2018369 .060
5.0L MPI Alpha, RWC 305/ V-8 Delco - HEI 2005 - 2006 0W310000 - 0W649999 866189T06(10) 8M0054588 84-863656A 1 33-8M2018369 .060
5.0L MPI Alpha, RWC 305/ V-8 Delco - HEI 2006 - 2008 0W650000 - 1A343327 866189T07(10) 8M0054588 84-863656A 1 33-8M2018369 .060
