Page 700 - Quicksilver Product Guide (2020) - 8M0163242

IGNITION

Model CID/ #Cyl Type of Ignition Year Range Serial # Range ECM/ ICM Ignition Coil Wire Kit Spark Plug Gap
5.7L EFI (Gen +) 350/ V-8 Delco - HEI 1998 0L336000 - 0L339999 861542T03 806673T 1 84-816608Q70 33-816336Q .045
5.7L EFI (Gen +) 350/ V-8 Mercury -HEI 1999 0L325977 - 0L325999 N.L.A. 300-8M0079202 84-816608Q83 33-816336Q .045
5.7L EFI (Gen +) 350/ V-8 Mercury -HEI 1999 0L331599 - 0L331991 N.L.A. 300-8M0079202 84-816608Q83 33-816336Q .045
5.7L EFI (Gen +) 350/ V-8 Mercury -HEI 1999 0L335716 - 0L335999 N.L.A. 300-8M0079202 84-816608Q83 33-816336Q .045
5.7L EFI (Gen +) 350/ V-8 Mercury -HEI 1999 - 2001 0L340000 - 0M299999 N.L.A. 300-8M0079202 84-816608Q83 33-816336Q .045
5.7L EFI MIE (Gen+) 350/ V-8 Delco - HEI 1997 0K040300 - 0K999999 N.L.A. 806673T 1 84-816608Q70 33-816336Q .045
5.7L MIE (LH) 350/ V-8 Thunderbolt IV 1988 - 1993 0B788152 - 0F024999 15899T02 300-8M0079202 84-816761Q 4 33-898264001 .035
5.7L MIE (RH) 350/ V-8 Thunderbolt IV 1988 - 1993 0B788152 - 0F024999 15899T02 300-8M0079202 84-816761Q 3 33-898264001 .035
5.7L MIE 350/ V-8 Thunderbolt IV(2) 1993 0F025000 - 0F622099 15899T02 300-8M0079202 84-816761Q 4 33-898264001 .035
5.7L MIE 350/ V-8 Thunderbolt IV(1) 1993 - 1995 0F025000 - 0F622099 N.L.A. 300-8M0079202 84-816761Q17 33-898264001 .035
5.7L MIE 350/ V-8 Thunderbolt IV 1995 0F622151 - 0F746099 N.L.A. 300-8M0079202 84-816761Q17 33-898264001 .035
5.7L MIE 350/ V-8 Thunderbolt V 1996 0F622100 - 0F622150 806956A01 300-8M0079202 84-816761Q17 33-898264001 .035
5.7L MIE 350/ V-8 Thunderbolt V 1996 - 1997 0F746100 - 0K999999 806956A01 300-8M0079202 84-816761Q17 33-898264001 .035
5.7L MIE (Gen+) 350/ V-8 Thunderbolt V 1998 - 2004 0L002003 - 0W090899 861543T02 300-8M0079202 84-816608Q80 33-816336Q .045
5.7L MIE (Gen+) 350/ V-8 Thunderbolt V 2004 - 2010 0W090900 - 1A092388 861543T02 300-8M0079202 84-863656A05 33-816336Q .045
5.7 MPI MIE, RWC 350/ V-8 Delco -HEI 2008 1A090000 - 1A091517 866126T04(10) 8M0054588 84-863656A 1 33-8M2018369 .060
5.7 MPI MIE, RWC 350/ V-8 Delco -HEI 2009 - 2015 1A091518 - 2A455523 879194T90(10) 8M0054588 84-863656A 1 33-8M2018369 .060
5.7 MPI MIE, RWC, EC 350/ V-8 Delco -HEI 2008 - 2011 1A090000 - 1A092817 8M0071882(10)(16) 8M0054588 84-863656A 1 33-8M2018369 .060
5.7 MPI MIE, RWC, EC 350/ V-8 Delco -HEI 2011 - 2016 1A092818 - 2A455371 78-8M0059359(10)(16) 8M0054588 84-863656A 1 33-8M2018369 .060
5.7 MPI MIE, FWC 350/ V-8 Delco -HEI 2008 1A090000 - 1A091517 866127T04(11) 8M0054588 84-863656A 1 33-8M2018369 .060 MERCURY® MERCRUISER®
5.7 MPI MIE, FWC 350/ V-8 Delco -HEI 2009 - 2015 1A091518 - 2A455523 879194T91(11) 8M0054588 84-863656A 1 33-8M2018369 .060
5.7 MPI MIE, FWC, EC 350/ V-8 Delco -HEI 2008 - 2011 1A090000 - 1A092817 8M0071881(11)(16) 8M0054588 84-863656A 1 33-8M2018369 .060
5.7 MPI MIE, FWC, EC 350/ V-8 Delco -HEI 2011 - 2016 1A092818 - 2A455371 78-8M0059360(11)(16) 8M0054588 84-863656A 1 33-8M2018369 .060
5.7 MPI MIE DTS, RWC 350/ V-8 Delco -HEI 2008 - 2010 1A090000 - 1A092168 866240T06(10)(13) 8M0054588 84-863656A 1 33-8M2018369 .060
5.7 MPI MIE DTS, RWC 350/ V-8 Delco -HEI 2010 - 2015 1A092169 - 2A455523 879194T96(10)(13) 8M0054588 84-863656A 1 33-8M2018369 .060
5.7 MPI MIE DTS, RWC, EC 350/ V-8 Delco -HEI 2008 - 2011 1A090000 - 1A092817 8M0071887(10)(13)(16) 8M0054588 84-863656A 1 33-8M2018369 .060
5.7 MPI MIE DTS, RWC, EC 350/ V-8 Delco -HEI 2011 - 2016 1A092818 - 2A455371 78-8M0059369(10)(13)(16) 8M0054588 84-863656A 1 33-8M2018369 .060
5.7 MPI MIE DTS, FWC 350/ V-8 Delco -HEI 2008 - 2010 1A090000 - 1A091825 866241T06(11)(13) 8M0054588 84-863656A 1 33-8M2018369 .060
5.7 MPI MIE DTS, FWC 350/ V-8 Delco -HEI 2010 - 2015 1A091826 - 2A455523 879194T97(11)(13) 8M0054588 84-863656A 1 33-8M2018369 .060
5.7 MPI MIE DTS, FWC, EC 350/ V-8 Delco -HEI 2008 - 2011 1A090000 - 1A092817 8M0071886(11)(13)(16) 8M0054588 84-863656A 1 33-8M2018369 .060
5.7 MPI MIE DTS, FWC, EC 350/ V-8 Delco -HEI 2011 - 2016 1A092818 - 2A455371 78-8M0059248(11)(13)(16) 8M0054588 84-863656A 1 33-8M2018369 .060
5.7 MPI Tow Sports 350/ V-8 Delco -HEI 2008 1A090000 - 1A091517 864299T10 8M0054588 84-863656A 1 33-8M2018369 .060
5.7 MPI Tow Sports 350/ V-8 Delco -HEI 2009 - 2015 1A091518 - 2A455977 879194T32 8M0054588 84-863656A 1 33-8M2018369 .060
5.7L MPI Tow Sports w/ Gen III 350/ V-8 Delco -HEI 2009 - 2015 1A091881 - 2A456039 87917215T 8M0054588 84-863656A 1 33-8M2018369 .060
5.7 MPI Tow Sports EC 350/ V-8 Delco -HEI 2008 - 2011 1A090000 - 1A092817 8M0071883(16) 8M0054588 84-863656A 1 33-8M2018369 .060
5.7 MPI Tow Sports EC 350/ V-8 Delco -HEI 2011 - 2015 1A092818 - 2A452508 78-8M0059361(16) 8M0054588 84-863656A 1 33-8M2018369 .060
5.7L Ski 350/ V-8 Prestolite 1985 - 1995 0A338553 - 0F775199 N/A 898253T24 84-816761Q12 33-898264001 .035
5.7L Ski 350/ V-8 Mallory 1985 - 1995 0A338553 - 0F775199 N/A 898253T24 84-816761Q12 33-898264001 .035
5.7L Ski 350/ V-8 Thunderbolt IV(2) 1987 - 1992 0B514627 - 0F775199 821125T02 300-8M0079202 84-816761Q 4 33-898264001 .035
5.7L Ski 350/ V-8 Thunderbolt IV(1) 1993 - 1995 0B514627 - 0F775199 N.L.A. 300-8M0079202 84-816761Q17 33-898264001 .035
5.7L Ski 350/ V-8 Thunderbolt V 1996 - 1997 0F775200 - 0K999999 807645A01 300-8M0079202 84-816761Q17 33-898264001 .035
5.7L Ski (Gen +) 350/ V-8 Thunderbolt V 1998 - 2004 0L002005 - 0W090899 861255T02 300-8M0079202 84-816608Q80 33-816336Q .045
5.7L Ski (Gen +) 350/ V-8 Thunderbolt V 2004 - 2006 0W090900 - 0W68999 861255T02 300-8M0079202 84-863656A05 33-816336Q .045
5.7L Ski (Gen +) 350/ V-8 Thunderbolt V 2006 - 2011 0W690000 - 1A092837 861543T02 300-8M0079202 84-863656A05 33-816336Q .045
5.7LX Alpha (4 bbl.) 350/ V-8 Thunderbolt V 1996 - 1997 0F601000 - 0K999999 807264A01 300-8M0079202 84-816761Q17 33-898264001 .035
5.7LX Bravo (4 bbl.) 350/ V-8 Thunderbolt V 1996 - 1997 0F601000 - 0K999999 806956A01 300-8M0079202 84-816761Q17 33-898264001 .035
5.7LX Bravo EFI (Gen +) 350/ V-8 Delco - HEI 1996 0F800300 - 0K001508 N.L.A. 806673T 1 84-816608Q70 33-816336Q .045
5.7LX Bravo EFI (Gen +) 350/ V-8 Delco - HEI 1997 0K001509 - 0K999999 N.L.A. 806673T 1 84-816608Q70 33-816336Q .045
5.7LX EFI 350/ V-8 Delco - HEI 1996 - 1997 0F752400 - 0K999999 N.L.A. 806673T 1 84-816608Q70 33-898264001 .035
Black Scorpion Ski (Gen+) 350/ V-8 Delco - HEI 1996 0F800000 - 0K040000 807696T 2 898253T27 84-816608Q68 33-816336Q .045
Black Scorpion Ski (Gen+) 350/ V-8 Delco - HEI 1997 - 1998 0K040001 - 0L005600 N.L.A. 898253T27 84-816608Q78 33-816336Q .045
Black Scorpion Ski (Gen+) 350/ V-8 Delco - HEI 1998 - 1999 0L005601 - 0L304549 N.L.A. 898253T27 84-816608Q81 33-816336Q .045
Black Scorpion Ski (Gen+) 350/ V-8 Delco - HEI 1999 - 2002 0L304550 - 0M391599 N.L.A. 898253T27 84-816608Q81 33-816336Q .045
Black Scorpion Ski (Gen+) 350/ V-8 Mercury - HEI 2003 - 2007 0M391600 - 0W698432 865155T06 8M0054588 84-863656A03 33-8M2018369 .060

Quicksilver Product Guide 691
