P. 116
FOURSTROKE MODELS
LOWER UNIT / GEAR HOUSING TOOLS BEARING RACE DRIVER
WASHER FOURSTROKE MODELS
91- 14308T02
Removes pinion bearing race.
12- 34961 BEARING INSTALLATION PULLER
.656 x 1.312 x .095, plain.
Used on the threaded puller rod between the nut and plate when removing
bearings.
MANDREL
91- 14309T02
Installs pinion bearing into gearcase.
WEAR SLEEVE DRIVER
91- 13658T
Aids in the installation of bushings, bearings and races into the gearcase.
BEARING INSTALL DRIVER
91- 14310T 1
Installs wear sleeve onto driveshaft.
BEARING PRELOAD TOOL
91- 13945
Installs reverse gear needle bearing into propeller shaft carrier.
OIL SEAL DRIVER
91- 14311A04
Simulates a load on the driveshaft for acurate pinion height and backlash
measurements.
91- 13949
Installs oil seals into water pump base.
Mercury Service Tool Guide 109
