Page 38 - Mercury Service Tool Guide (2020) - 8M0163249
P. 38
ZEUS 3000 SERIES POD DRIVE
BEARING DRIVER GEARCASE SUPPORT ASSEMBLY
91-8M0155308
Used to support the gearcase while performing maintenance.
TORCH LAMP
91-8M0007683
Aids in the installation of the propshaft bearing cup.
BEARING DRIVER
91- 63209
Heats surfaces to aid in the removal and installation of interference fit engine
componenets.
91-8M0007681
Aids in the installation of the bearing cup.
HEIGHT GAGE
91-8M0007677
Aids in the checking of pinion gear height.
PRELOAD TOOL ZEUS 3000 SERIES POD DRIVE
91-8M0030456
Aids in the checking of preload of the inner propshaft.
PROPSHAFT SUPPORT TOOL
91-8M0030271
Aids in the assembly of the gearcase by supporting the inner propshaft.
Mercury Service Tool Guide 31
