Propeller Selection
MerCruiser Repower Propeller Charts

Propellers ‑ For Single Engine Boats

Plus Series ‑ 3.0L TKS Alpha ‑ (135 HP) ‑ In‑line‑4 Alpha
Propellers ‑ For Single Engine Boats
WOT: 4400–4800 RPM, Standard Gear Ratio 2.00:1
High Altitude (1524 m [5000 ft])+ Gear Ratio: 2.40:1
Right‑Hand Rotation Standard
Approximate Gross Boat
Diameter Pitch Blades Material Approximate Boat Length Speed Range
Weight
40.6 cm 27.9 cm 3 Aluminum 3175 kg House/Work 2–26 kph
(16 in.) (11 in.) (7000 lb)+ (1–16 mph)
40.6 cm 30.5 cm 2722 kg 16–31 kph
(16 in.) (12 in.) 3 Aluminum (6000 lb)+ House/Work (10–19 mph)
40.6 cm 33 cm 3 Aluminum 2177–3946 kg 7–8.8 m 21–35 kph
(16 in.) (13 in.) (4800–8700 lb) (23–29 ft) (13–22 mph)
40.6 cm 35.6 cm 1996–3357 kg 6.7–8.5 m 24–39 kph
(16 in.) (14 in.) 3 Aluminum (4400–7400 lb) (22–28 ft) (15–24 mph)
39.4 cm 38.1 cm 3 Aluminum 1724–2767 kg 6.4–7.9 m 29–43 kph
(15.5 in.) (15 in.) (3800–6100 lb) (21–26 ft) (18–27 mph)
40.6 cm 40.6 cm 3 Aluminum 1542–2313 kg 6.1–7.6 m 34–48 kph
(16 in.) (16 in.) (3400–5100 lb) (20–25 ft) (21–30 mph)
38.1 cm 43.2 cm 1451–1996 kg 7.6–7 m 38–52 kph
(15 in.) (17 in.) 3 Aluminum (3200–4400 lb) (20–23 ft) (24–32 mph)
39.4 cm 45.7 cm 3 Aluminum 1315–1814 kg 5.8–7 m 42–56 kph
(15.5 in.) (18 in.) (2900–4000 lb) (19–23 ft) (26–35 mph)
36.8 cm 48.3 cm 1224–1588 kg 5.5–6.7 m 47–60 kph
(14.5 in.) (19 in.) 3 Aluminum (2700–3500 lb) (18–22 ft) (29–37 mph)
36.2 cm 55.3 cm 3 Aluminum 1043–1315 kg 5.2–6.1 m 56–68 kph
(14.25 in.) (21 in.) (2300–2900 lb) (17–20 ft) (35–42 mph)
35.6 cm 58.4 cm 3 Aluminum 953–1134 kg 4.9–5.8 m 64–76 kph
(14 in.) (23 in.) (2100–2500 lb) (16–19 ft) (40–47 mph)
35.6 cm 43.2 cm 1451–1996 kg 7.6–7 m 39–52 kph
(14 in.) (17 in.) 4 Aluminum (3200–4400 lb) (20–23 ft) (24–32 mph)
35.6 cm 48.3 cm 4 Aluminum 1225–1588 kg 5.5–6.7 m 47–60 kph
(14 in.) (19 in.) (2700–3500 lb) (18–22 ft) (29–37 mph)
35.6 cm 55.3 cm 1043–1315 kg 5.2–6.1 m 56–68 kph
(14 in.) (21 in.) 4 Aluminum (2300–2900 lb) (17–20 ft) (35–42 mph)
35.6 cm 58.4 cm 4 Aluminum 953–1134 kg 4.9–5.8 m 64–76 kph
(14 in.) (23 in.) (2100–2500 lb) (16–19 ft) (40–47 mph)
36.8 cm 43.2 cm 1451–1996 kg 7.6–7 m 39–52 kph
(14.5 in.) (17 in.) 3 Stainless Steel (3200–4400 lb) (20–23 ft) (24–32 mph)
35.6 cm 48.3 cm 1224–1588 kg 5.4–6.7 m 47–60 kph
(14 in.) (19 in.) 3 Stainless Steel (2700–3500 lb) (18–22 ft) (29–37 mph)
34.9 cm 55.3 cm 3 Stainless Steel 1043–1315 kg 5.2–6.1 m 47–60 kph
(13.75 in.) (21 in.) (2300–2900 lb) (17–20 ft) (29–37 mph)
34.3 cm 58.4 cm 953–1134 kg 4.9–5.8 m 64–76 kph
(13.5 in.) (23 in.) 3 Stainless Steel (2100–2500 lb) (16–19 ft) (40–47 mph)

90-8M0149179 eng NOVEMBER 2018 © 2019 Mercury Marine Page 4B-11
