Page 146 - Toro Irrigation Product Catalogue August 2020

Shrubbler 360˚ & 180˚ Adjustable Flow
®

Application

The original patented Shrubbler with flow adjustment.
®
Flow and coverage can be altered by rotating the cap.
Use with pots, tubs, landscaped gardens, nurseries,
hanging baskets. In-Line spike model for planter boxes.

Features
• Finger-tip flow control with shut-off option
• Spike model to anchor Shrubbler at the plant
®
• Barb model for direct attachment to feeder and supply
lines Performance
• Threaded model for installation into Rigid Risers and
Asta Stakes 360˚ 180˚
®
• 1/2” Threaded model for riser pipe installations Pressure Flow (Lph) Diameter (m) Radius (m)
• In-Line spike model suits 4 mm ID connection tube (kPa)
fully open 100 33 0.4 0.4
(approx.
22 clicks) 150 41 0.6 0.5
200 49 0.9 0.6

Shrubbler ®
Spike 4 mm

Shrubbler ®
Barb 4 mm

Shrubbler ®
Thread 4 mm
Ordering Information

Code Description
10131445 Shrubbler 360˚, 4 mm Barb
10131415 Shrubbler 360˚, 4 mm Thread
10131425 Shrubbler 360˚, ½” FNPT Thread
10131495 Shrubbler 360˚, Spike

Ordering Information

Code Description
10131245 Shrubbler 180˚, 4 mm Barb
10131215 Shrubbler 180˚, 4 mm Thread
10131225 Shrubbler 180˚, ½” FNPT Thread
Shrubbler ® Shrubbler ®
10131295 Shrubbler 180˚, Spike In-Line Spike 4 mm Thread 1/2”
FNPT
