Turf Guard Soil Monitoring System cont.
®

Specifications How it works:
Multiple sensors buried in a site at critical root zone levels.
Dimensions
Above-ground repeaters installed on or in existing irrigation
• Body: 50 mm (W) x 92 mm (H) x 156 mm (D) controller enclosures.
• Spikes: 44 mm x 5 mm
• Installation Hole Diameter: 108 mm Wireless MESH networking links all sensors to central computer
Moisture, Temperature and Salinity readings displayed in your office
Electrical Specifications
• Input Power:
• Repeater: <.02A @ 6 VDC Sensor
• Base Station: 240 VAC, 50 Hz
Measures soil moisture, temperature, and
Temperature Specifications salinity.
• Operating: 0°C to 60°C
• Storage: -30°C to 82°C
Sensing
• 0.1°C Temperature resolution
• 0.1% Volumetric soil moisture content resolution
• 0.1 dS/m Soil conductivity resolution (Salinity) Repeater

Communication Can run off of a standard 240V outlet or
controller power-supply with adaptor.
• Repeater Range: Up to 1525 m line-of-sight
• Buried Sensor Range: Up to 150 m line-of-sight Multiple sensors can be run through just one
• 900 MHz FHSS Communication repeater, no configuration required.
• Additional licensing not required

Operating Specifications and Additional Features
• Password Protected Web-based Interface Base Station
• Moisture Data available in Sentinel® Software Interface
• Immediately ready for operation after installation Connects to Internet in the office.
• Advanced MESH routing technology overcomes obstacles
• Repeater can adapt to standard 240V outlet
• Durable sensor housing is resistant to aeration damage
• Supports up to 500 sensors per system
• Expected sensor battery life of 3 years, field replaceable
• Sensor reading sent every 5 minutes
• Automatic network configuration and failure recovery
• Graphical system overview displays sensor data-at-a-glance Web-based Interface
• Plots trends and compares historical and current readings View current sensor readings and
• Move quickly from system-wide averages to individual sensor historical data remotely from any Web-
readings connected computer or Web-enabled
Mobile Phone or PDA.
Warranty
• Comes with 1 year of NSN support (extended support plans
available)

Turf Guard Model List
Model Description
AU
TG-S2-R-AU Turf Guard Sensor With Replaceable Battery
TG-R-INT-AU Repeater-Internal Mount
TG-R-EXT-AU Repeater-External Mount
TG-B-AU Base Station
TG-PS-AU Power Conversion Board
TG-S2-BAT Replacement Battery
TS-TGB Turf Guard Receiver for Sentinel
