Sentinel Soil Sensing
®
Specifications
• 1 sensor assignable per program
• 16 sensors per controller
• Sensor data read every 5 minutes
• Ability to work in conjunction with ET-based control
Ordering Details
Code Description
TG-B-AU Turf Guard Base Station
TG-S2-R-AU Turf Guard Sensor
TG-R-INT-AU Turf Guard Internal Repeater
TG-R-EXT-AU Turf Guard External Repeater
Using Turf Guard® soil sensor, Sentinel users can TG-PS-AU Turf Guard Power Conversion Board
set upper and lower moisture level “trip points” TG-S2-BAT Turf Guard Replacement Battery
in the software to regulate when irrigation is TS-TGB Turf Guard Receiver for Sentinel
allowed, as well as view the trends over time on
an at-a-glance dashboard.
Sentinel Flow Sensing
®
Specifications
• Two flow inputs available on all Sentinel controllers
• High, low, and zero flow detection by station or group of
stations
• Unexpected flow detection outside of scheduled watering
• Volumetric flow shutdown option
• Projected and actual flow graphing
• Data exportable to customized Excel spreadsheets
• Each controller stores two years of flow data
Ordering Details
Code Description
TFS-050 15 mm Slip x Slip PVC Impellor Flow Sensor
Toro Sentinel satellites have extensive flow TFS-075 20 mm Slip x Slip PVC Impellor Flow Sensor
reading, reaction, and reporting capabilities. All TFS-100 25 mm Slip x Slip PVC Impellor Flow Sensor
controllers come with two flow inputs and two TFS-150 40 mm Slip x Slip PVC Impellor Flow Sensor
alarm inputs available, and are compatible with TFS-200 50 mm Slip x Slip PVC Impellor Flow Sensor
both standard flow sensors as well as most
hydrometers, including reed-switch and 3-wire TFS-300 80 mm Slip x Slip PVC Impellor Flow Sensor
pulse-diode models. TFS-400 100 mm Slip x Slip PVC Impellor Flow Sensor
FS-INSERT-B Insert Type Flow Sensor to suit 80 mm to
400 mm (tapping band required)
