Sentinel Controllers cont.
®

Specifications

Dimensions Specifications and Features (cont.)
• Small wall-mount: • Ability to connect to a laptop to download large station
260 mm (W) x 387 mm (H) x 133 mm (D) count programs
• Weight: 9.5 kg • Upgrade to a central computer system without additional
field satellite hardware or costs
Electrical Specifications • Program single or multiple stations to operate sequentially
• Input power: or start a program or multiple programs with just a few
• 240 VAC/50 Hz keystrokes
• Station output power: • Ability to read open- or closed-contact switches in any
• 24 VAC station count configuration
• 1.0 amps per station maximum • Current monitor will disable a station if excessive amp draw
• 2.0 amps total load is detected
• Surge protection: 24 V output boards, 20 KV @ 10 KVA • Non-volatile memory will retain all programming and real-
time data for 10 years
Specifications and Features • Operating temperature: -10° to 60°C
• Surge rated to 20 KV @ 10 KVA
• 16 programs
• Eight start times per program Optional Accessories
• 6-week scheduling calendar
• Station runtimes from one minute to 4 hours • TRS: Wired RainSensor
and 15 minutes • TWRS/TWRFS: Wireless RainSensor or Wireless Rain/
• Global adjustment from 0-255% Freeze Sensor
• Flow sensor ready • TFS: Flow Sensors
• Turf Guard ready • TS-TGB: Turf Guard Base Station Module for Sentinel
• Two sensor inputs included for rain sensors or other switch Satellite Connectivity
sensors
• ET and soil sensing options Warranty
• Operating temperature: -10˚ to 60˚C • Five years

Sentinel® Wireless Wall Mount Controller

Sentinel Wireless Specifications
Output Boards utilize
spread spectrum radio Operational
communication between • Wireless Output Controllers allow expansion of Sentinel
the control module and the Master Controllers to 204 stations
output boards, allowing • Ability to mount outputs remote from Sentinel® Control
nearly unlimited installation Module
flexibility while virtually - No cabling between output boards and control module
eliminating surge damage
to the control module. improves protection of control module from power surges
Retrofits and remote flow • Improved sensing includes real-time current draw per station
sensing are a snap as • Manual station activation switches
hardscape crossing issues • Long range and short range models
are eliminated.
Dimensions
Warranty • Small wall mount 360 mm (W) x 330 mm (H) x 150 mm (D)
• Five years

Specifying Information—Sentinel

TS-XXX-XX-XXX-NR-50HC
Communication
Configuration Wireless Range Station Count Enclosure Power Supply
to Central
TS XXX XX XXX NR 50HC
TS— Conventional Toro WSR— Short Range Wireless 12—12-station WS1—Powder-Coated Wall Mount (Small) NR—No Radio 50HC—220-240V/50Hz
Sentinel Satellite WLR— Long Range Wireless 24—24-station
Blank— wired 36—36-station
48—48-station
Example: A 24-station wired Sentinel Controller in a powder-coated wall-mount cabinet would be specified as: TS24WS1NR50HC
