Sentinel Two-Wire Controllers
®

Specifications

Operational

• Up to 204 stations
• Operates Valves with DC-Latching Solenoids
• 16 programs, eight start times per program
• 6-week or 365-day scheduling calendar
• Station runtimes from one minute to 4 hours and 15 minutes
• Global adjustment from 0-255%
• Flow sensor ready
• Two sensor inputs included for rain sensors or other switch
sensors
• Operating Temperature: 0° to 60°C
Electrical
• Input power:
- 240 VAC (50 Hz)
• Output power:
- Up to 2 DC latching solenoids per station
- Up to 16 simultaneous DC latching stations
Easy to install and expand – a highly cost • Two-wire path wiring (jacketed, twisted pair):
2
- 2.1 mm
effective field controller for large central - 4200 m max
control installations. Using a two-wire path to • Decoder-to-solenoid wiring:
- 1.5 mm
2
communicate to decoders, the Sentinel Two- - 150 m max
Wire controller eliminates high costs associated
with traditional valve wiring. Dimensions
• Small wall-mount: 36 cm W x 33 cm H X 15 cm D
• Weight: 9.5 Kg

Flow Soil Optional Accessories
Sensor Sensing
Compatible Option • TRS – Wired RainSensor
• TWRS/TWRFS – Wireless RainSensor or Wireless Rain/Freeze
Sensor
• TFS – Flow Sensors
DC Sentinel Two-Wire Station Decoders • TS-TGB - Soil Sensor Receiver Base Station Module
Model Description Warranty
DEC-ISP-1 1-station with integrated surge protection • Five years
(Operates up to two DC latching coils)
DEC-ISP-2 2-station with integrated surge protection
(Operates up to four DC latching coils)
DEC-ISP-4 4-station with integrated surge protection
(Operates up to eight DC latching coils)
DEC-SG-LINE Sentinel two wire DC inline surge protection

Specifying Information—Sentinel
TS-X-XXX-NR-50HC
Communication
Configuration Station Count Enclosure Power Supply
to Central
TS XX XXX NR 50HC
TS— Conventional Toro D-Decoder WS2—Powder-Coated Wall Mount Decoder NR—No Radio 50HC—220-240V/50Hz
Sentinel Satellite 204 station

A wired Sentinel DC Controller in a powder-coated wall-mount cabinet would be specified as: TSDWS2NR50HC

Company policy is one of constant improvement and therefore changes in specifications may
266 be made without notice and without incurring liability. Please refer to www.toro.com.au
