Spray Tools and Accessories

Effluent Water Indicators Serviceable Parts Tools

89-6395
570SEAL • Riser pull-up and screen removal tool
• Serviceable seal for all 570Z models for all 570Z Series models
• Recommended for upgrades

118-1302 Risers and Extenders
• Lavender molded cover for use on
570Z Series pop-up models
89-7350
570-6X • Adjustment tool for all 570Z Series
• 570Z Extender models
• Male-inlet threads
install onto any 570Z
pop-up sprinkler or
102-1211 shrub adapter to
• Lavender molded cap for use on provide a 15cm (6”)
570Z Series pop-up models extension
• Includes wiper seal • Maximum pressure:
520 kPa (75 psi) PRNTOOL
• PRN Adjustment Tool for Precision™
Series Rotating Nozzles
• Adjusts arc and radius

Check Valve 570CV
• Check valve for all 570Z models
• Install in field to prevent low head
102-0563 drainage
• Lavender molded 570Z Series shrub
adapter
• Installs onto a 13 mm (½”) NPT riser
PNOZZTOOL
• Robust riser pull-up and screen
removal tool
• Retrofit all brands and all spray-head
models
• Patent protected

Precision Check Valve PCV-500
• 15mm (½”) male x female thread
• Holds back 4.5 mm (15’) elevation change
• Prevents low head drainage

PCV-500 Pressure Loss Data
Flow rate 4 8 12 16 20
(Lpm)
Pressure 35 41 45 48 70
Loss (kPa)
