HS Series Accessories
R

533 Bubbler

Designed for localized watering of flower beds,
roses, shrub areas and ground covers, Irritrol’s
533 Bubbler is the only hand-adjustable flood
bubbler that shuts down to a true zero flow.

Features

• Simple Twist Top Flow Adjustment
Easily adjusts by hand with no tools needed!
• True Zero Flow Shut-Off
Allows for temporary maintenance needs
• Fully Adjustable Arc and Flow Rate
For flexibility in precise watering needs
• Heavy-duty ABS Material
Provides durability and long-lasting life Performance Data
90° Adjust 180° Adjust 270° Adjust 360° Adjust
Specifications kPa Lpm Lpm Lpm Lpm
103 5.2 9.0 10.8 11.3
• Recommended working pressure: 137-275 kPa
• Flow rate: 5.2-22.4 Lpm 138 5.9 10.4 12.5 13.1
• Maximum operating pressure: 517 kPa 172 6.7 11.5 14.1 14.6
• Inlet size: 15 mm (1/2”) female uni-thread 207 7.3 12.7 15.3 16.4
• 5 year warranty 241 7.6 13.6 16.6 20.9
Dimensions 276 8.5 14.6 17.8 22.4
• H: 29 mm
• Top diameter: 27 mm

HS100 Shrub Adaptor
Designed for use with all Irritrol spray head
nozzles in shrub and other low traffic areas
to mount HS Series nozzles to 15mm MBSP
threaded risers.

Features

• Suits HS, LS and I-Pro series nozzles
• 15mm female uni-thread inlet
• Threads directly onto riser
• UV-treated for above-ground mount
• Manufactured of heavy-duty ABS
• Accepts all Irritrol nozzles and any other
female-threaded nozzle
• 5 year warranty Ordering Information
Code Description
533 Adjustable Bubbler, 15mm female uni-thread inlet
HS100 Shrub Adaptor to suit Irritrol nozzles
