SWING JOINTS

toro.com.au

Toro offers a full line of swing joints.
Toro swing joints cover all golf sprinkler thread types. Swing joints provide
the flexibility to align the sprinkler to proper grade and level positioning to
ensure optimum water use through maximum nozzle distribution uniformity.

Features & Benefits

1 Minimise Friction Loss 3 Standard 2X90 and Ultra 4X90 Outlet
2.54 3.18 and 3.81cm (1”, 1.25” and 1.5”) models
Configurations
are available to cover flows exceeding 80 gpm, and The standard 2x90 models provide two 90’s at the
minimise friction loss to ensure optimum pressure is outlet for alignment in two directions and the Ultra
available at each sprinkler. 4x90 models provide four 90’s at the outlet for

2 Saddle and Glue Tee Models maximum alignment flexibility in four directions.
Two swing joint types are available with 2” service
Quick Coupler Models
tees included; glue tees for PVC piping applications 4 Available with a quick coupler outlet that includes
and saddle tees for HDPE piping applications. Both both an anti-rotation and position stabilising feature
tee styles are available with 2.54, 3.18 and 3.81cm to ensure the quick coupling valve stays secure
(1”, 1.25” and 1.5”) double o-ring sealing outlets. during key installation and removal.
