SPRINKLER TOOLS

995-15 Valve Removal 995-100 Valve
Selector Tool Tools Snap Ring Pliers
• All electric golf • 995-08 All 1” golf with Screen
sprinklers models and 640 Remover
• Allows user to • 995-09 All 1.5” • All Golf sprinklers
manually turn the models and 690 lower snap ring
sprinkler “ON”, turn removal on all
or leave it “OFF” models
or place it into the
“AUTO” position Nut Drivers • Rock screen removal
®
awaiting a command • 995-105 5/16” on all INFINITY ,
®
from the controller INFINITY , FLEX800, FLEX800, DT and
DT and 800S Series 800S Series
TruJectory adjustment • Valve removal on all
on INFX5-6/ FLX5-6 models
models
- Inner, intermediate
995-83 Multi and back nozzle Riser Hold Up
Purpose Tool removal on all DT Tools
• All Golf sprinklers and 800S models Allow for Nozzle
• Riser pull up for • 995-99 5/8” Servicing
INFINITY , FLEX800, - Dual trajectory • 118-0954 Riser hold
®
DT and 800S Series selection up tool, red
• Riser screen - Main nozzle removal • 995-55 All 700 models
removal on all on all models • 995-102 Universal
models hold up tool, all 700,
• 995-79 7/16”
• Upper snap ring 834S/854S pre 800S, DT, INFINITY ®
remover on all August 2007 and FLEX800 models
models - Inner, intermediate and
back nozzle removal
- 650/760/780/860S/ PRNTOOL
• Adjustment tool for
880S Inner, Precision Series
™
intermediate and Rotating Nozzles
back nozzle removal
995-82 Arc • Adjusts arc and radius
Adjustment Tool, • 995-81 9/16”
760/780 Series Main
3/32” Allen nozzle removal
Wrench • 995-80 1/2”
• 765,785,865S,885S 760/780/860S/880S
Arc adjustment of Nozzle base jam nut
the part circle drives removal PNOZZTOOL
• INFINITY , FLEX800, • 995-53 3/8” 660/680 Riser Pull Up Tool
®
DT and 800S Series. Cap nut removal • Used on 590GF
Adjustment of the sprays
radius reduction screw
Valve Insertion
Tools
Riser Removal Aligns and Installs
Tools Valve into the Body
• 995-85 drive • 995-35 640 VIH body
assembly extraction • 995-76 All 1” golf
tool 730, 760, 780, models (Except 102-6527
860S,880S INFINITY ) ® • T7 Rotor adjustment
- Threads onto the • 995-101 All 1.5” tool
drive output shaft golf models (Except
and allows removal INFINITY ) ®
of the drive from
the body • 995-12 690 body
• 118-1843 INFINITY ®
1.5” models
• 118-1844 INFINITY ®
1" models 118-0954
• Riser hold up tool

119
