PROTRONICS CO.,LTD.

78 Measuring Instruments Store
Line: @ponpe / Facebook: »¹à» / Tel: 02-5316293,5-6 / Website: www.ponpe.com

Ultrasonic Thickness Gauge เครื่องวัดความหนา

GM100 GM130 GM280F

Specifications Specifications Specifications
Working frequency : 5MHz Measuring range: 1.0~300mm Measuring range : 0~1800µm
Measuring range : 1.2 to 225.0mm (steel) Accuracy: ±(1%H+0.1) mm Accuracy : ±ʢ3%H±1µmʣ
Accuracy : ±(1%H+0.1)mm Resolution: 0.01mm Resolution : 0.1µm (<100µm) or 1µm(>100µm)
Sound velocity range : 1000 to 9999 m/s Sound velocity range: 1000~9999m/s Data store/ Data recall/ Data delete function
Operation temperature : 0 to 40°C Working frequency: 5MHz Measure in Metric/Imperial
Operation current : ≤50mA Auto calibration to assure the accuracy Beep sound indication

CG104 CG304

Specifications
Ferrous Non-Ferrous Specifications
Magnetic Induction Eddy Current
Range : Ferrous Probe, 0 to 2000 micro mils; 0 to 78.7mils
Range 0 to 2000µm 0 to 1000μm
Non Ferrous, 0 to 2000 micro mils; 0 to 78.7 mils
(0 to 80.0mils) (0 to 40.0mils)
Resolution µm (0.1mils) 1µm (0.1mils) Accuracy : Ferrous Probe, more or less than 2 percent with 2
±4 digits (0 to 7.8mils); ±4 digits (0 to 7.8mils); micro mills; More or less than 3.5 percent 1000 to 2000 micro mils
±10 digits (o to 199µm) ±10 digits (o to 199µm) Non Ferrous Probe, more or less than 2 percent with 2 micro mils;
Basic ±3% (7.9 to 39.0mils); ±3% (7.9 to 39.0mils); More or less than 3.5 percent1000 to 2000 micro mils
Accuracy ±3% (200µm to 1000µm) ±3% (200µm to 1000µm) Resolution : Ferrous Probe, 0.1 micro mils 0.01mils
±5% (39.1 to 80.0mils); Non Ferrous Probe, 0.1 micro mils 0.01mils
±5% (1001µm to 2000µm)
CG204 CG206

Specifications Specifications
Range: -50.0~300°C; -58.0~572°F Range : -50 ~ 300°C (-58 ~ 572°F)
Resolution: 0.1°C /0.1°F Accuracy : -10~100°C: ±1 °C; 100~200°C: ±1.5°C
Accuracy: ±1°C@ -10°C~ +100°C -50~-10°C : ±2°C; 200~300°C :±2°C
±2°C@ -20°C~-10°C / +100°C~+150°C Rest :±2% Resolution : 0.1°C/°F
Data-hold function Operating Temperature : 0 ~ 40°C (32 ~ 104°F)
Sampling time: 2 secs Operating Humidity : 10-90% RH
Power : 1*CR2032 Battery

38/40-41 ËÁÙ‹·Õè 3 ¶¹¹ÅÓÅÙ¡¡Ò µÓºÅ¤Ù¤µ เครื่องวัดความหนา
ÍÓàÀÍÅÓÅÙ¡¡Ò ¨Ñ§ËÇÑ´»·ØÁ¸Ò¹Õ 12130
