PROTRONICS CO.,LTD.

77 Measuring Instruments Store
Line: @ponpe / Facebook: »¹à» / Tel: 02-5316293,5-6 / Website: www.ponpe.com

DT2236B DT2236C DT2240B

Specifications Specifications Specifications
Range : 2.5 - 99999 rpm (laser mode) Measurement : Photo Tach : 2.5 ~ 99,999 RPM Measure range : 60~39,999RPM
0.5 - 19999 rpm (contact mode, linear surface speed) Contact Tach: 0.5~19,999RPM Coarse/Fine adjust amplitude: ±0.1RPM
0.05 - 1999.9 m/min (contact mode, linear surface speed) Surface Speed : 0.05 ~ 1,999.9m/min; ≥1,000RPM Coarse adjust:±100RPM
Resolution : 0.1 rpm (2.5-999.9 rpm) 0.2~ 6,560 ft/min Fine adjust: ±1RPM
1 rpm (above 1000 rpm) Detecting Distance: 50~500mm/2~20” Accuracy: ±0.05%
0.1 rpm (0.5-999.9 rpm) / 1 rpm (above 1000 rpm) Operation Temperature : 0~50°C(32~122°F) Resolution: ≥1,000RPM: 1RPM
Accuracy : ±0.05% + 1 digit Accuracy : ±(0.05% +1 digit)
RPM33 RPM40 DT-2350P

Specifications Specifications Specifications
Photo mode Contact mode Photo mode Contact mode Range : 50 - 12,000 FPM (Flash per minute)
Range (rpm) 2 to 99,999 rpm 2 to 20,000 rpm Range (rpm) 5 to 99,999 rpm 0.5 to 19,999 rpm Resolution : 0.1 FPM (50 - 999.9 FPM)
Surface Speed - 0 to 78,720 inches/min Surface Speed 2.0 to 78,740 “/min 1 FPM (over 1000 FPM)
- 0 to 6560 ft/min 0.2 to 6560 ft/min Accuracy : ± (0.05%n + 1d)
- 0 to 2186 yards/min 0.05 to 1999.9 m/min Sampling Time : 0.3 second
- 0 to 2000 m/min Accuracy ±(0.1% rdg +1 digit) ±(0.1% rdg +1 digit) Strobe Flash tube type : Xenon lamp
Length - 3.9 to 39370 inches Sampling Time 1 sec (> 60 rpm) 1sec (> 6 rpm) Operating condition : 0 - 40°C , below 85% RH
- 0.3 to 3280 feet Resolution 0.1rpm (< 1000 rpm) Power supply : 220V A.C.
- 0.1 to 1093 yards 1rpm (> 1000 rpm) Unit size : 215 x 85 x 180 mm (8.5 x 3.3 x 7.1 inch)
- 0.1 to 1000 meters
Frequency (Hz) - 333 Hz
Accuracy 0.05% rdg +1 digit 0.05% rdg +1 digit

38/40-41 ËÁÙ‹·Õè 3 ¶¹¹ÅÓÅÙ¡¡Ò µÓºÅ¤Ù¤µ เครื่องวัดความเร็วรอบ
ÍÓàÀÍÅÓÅÙ¡¡Ò ¨Ñ§ËÇÑ´»·ØÁ¸Ò¹Õ 12130
