REMOTE CONTROLS AND INTERFACES REMOTE CONTROLS AND INTERFACES
Remote Controls
WPa Series WPa Series

APPLICATIONS

WPaVOL WPaVOL-J WPaVOL-SR

WPaMIX-T WPaMIX-TUS (with USA frame)

WPaVOL-SR-J WPaH-SL4 WPaH-AT6

WPaCNX-JRCA WPaCNX-CBO

WPaH-AT40 WPaH-AT100

Different mounting options available:
Fully with single/double, surface/flush WPa series mount boxes

WPaVOLUS (with USA frame) WPaVOL-SRUS (with USA frame)

US single gang bare format.
WPa is a series of remote control wall panels for systems and interconnecting audio signals, with a modern,
elegant, discrete aesthetic, designed in collaboration with Italdesign Giugiaro.
WPa series includes surface-mount installation box (except UBWPa).
WPaVOL is a remote wall panel control for one volume management. Compatible with all 0-10V DC REMOTE
ACCESSORIES control port. UBWPaVOL UBWPaCNX-JRCA
WPaVOL-J has the same features as WPa VOL + front panel stereo mini-jack connector.
WPaVOL-SR is a remote wall panel control for one volume management + source or preset selection. WPaMIX-T is a 2 channel micro-mixer which keeps the standard wall-panel format of the WPa series. It
Compatible with all 0-10V DC REMOTE control port. allows to a mix a stereo unbalanced signal (2 x RCA) with a microphone signal (XLR), getting a balanced
WPaVOL-SR-J has the same features as WPaVOL-SR + front panel stereo mini-jack connector. mono output that can be sent to a preamplifier, amplifier, mixer, digital or analogue matrix, etc., thus saving
WPa2SMBOX WPaH-AT6 is a 70 / 100V line attenuator with integrated 24 VDC priority relay. 6W maximum output power. inputs in the receiver device.
WPaH-AT40 is a 70 / 100V line attenuator with integrated 24 VDC priority relay.40W maximum output The MIC input includes a 2 band EQ (BASS, TREBLE) and it can use the talk-over function to override the line
power. signal when the microphone exceeds the talk-over detection threshold. Power supply not included (WP24-PSU).
WPaH-AT100 is a 70 / 100V line attenuator with integrated 24 VDC priority relay. 100W maximum output WPaCNX-CBO is a connection Wall Plate with Female 3 pin XLR connector + Jackk ST (combo connector).
power. Screw-type connector at the back (no solder needed).
WPa2FMBOX WPaH-SL4 is a 70 / 100V V line selector (one out of 4 music program lines). WPaCNX-JRCA is a connection Wall Plate with 1 x stereo minijack and 2 x RCA connectors.
