bit. When the user enters the binary number to be converted, the Bit sprite
should receive the BinaryToDecimal message and execute the script shown in
Figure 8-22.

Initialize all variables
 before entering the main
processing loop.

Start a loop to check all
the digits of the input
 binary number in reverse
order starting with the
rightmost digit.

If the digit is a 1, update
the variable decimal by the
 weight of the digit. Then
stamp the costume for
digit 1 at the correct
position on the Stage.

Get ready to process the
 next digit (to the left of
the one that we just
processed).

Figure 8-22: The BinaryToDecimal script for the Bit sprite

First, the conversion procedure initializes all of the variables it will use u:

• length is the number of bits in the user’s binary number.
• pos points to the rightmost digit of the input number.
• weight starts at the positional value of the rightmost binary digit.
• decimal is set to 0 but will hold the result of the conversion at the end.
• xPos begins at the x-coordinate of the image of the rightmost binary digit.

Inside the repeat loop v, the procedure checks each digit to see whether
it is a 1 or a 0. If the loop finds a 1 w, it adds the current value of weight to
decimal and stamps the digit-1 costume on top of the digit-0 image.
At the end of the loop, the script updates several variables before mov-
ing to the next iteration:
• pos is updated to point to the digit to the left of the one we just processed.
• xPos is aligned with the center of the image of the next digit, just in
case we need to stamp a new image.
• weight is multiplied by 2, which means it will take on the values 1, 2, 4,
8, 16, and so on as the loop iterates.
