5.2
where: qci = consolidation resistance
*α can be decided using table 20-4
Ab = end cross-sectional area of the pile
Ami = shaft area of the pile in contact with the soil.
should be ≥ 2.5 for piles in friction material
qcs = end resistance at the bottom of the pile within 4 ⋅ pile diameter from the end
of the pile
© It's Engg. Life
Figure 5-2 Friction Pile
Example 5.2
Pile length 22 m, steel pile, friction pile, external diameter 200 mm, GC2,
Determine the ultimate bearing capacity of the pile
solution:
qc
Z↓ m( depth measured from ground MPa
level to bottom of pile)
